Detailed configuration of 26 seater China new Desel Mini Bus with air conditioner Overall Parameter
| Overall length(mm) | 7235 |
| Overall width (mm) | 2260 |
| Overall height (mm) | 2810/2980 |
| Wheelbase(mm) | 3800 |
| Front/Rear overhang (mm) | 1200/2235 |
| Approach/departure angle(°) | 18/9 |
| Front/Rear Tread (mm) | 1860/1610 |
| Gross Weight(kg) | 7700 |
| Rated Passengers | 24-27 |
| Top Speed (km/h) | 100 |
Engine Parameter
| Engine Model | YC4D130-30 |
| Engine Position/Fuel | Front/Diesel |
| Type | Inline cylinders,4 strokes,water-cooling,turbocharger-intercoller, electricity control |
| Max Power (kw/r/min) | 96/2800 |
| Max Torque (N.m/r/min) | 420/1400-1800 |
| Displacement | 4.214L |
| Emission standard | Euro Ⅲ |
Chassis Parameter
| Chassis Mode/Manufacture | EQ6690K3AC |
| Transmission | DF5S550 |
| Charging generator | 120Ah×2/100A 28V |
| Clutch | φ350 single,dry style , diaphragm spring,Clutch booster |
| Front axle | ''H" section forged modeling 3T |
| Driving axle | Integral Casting 5T , Main reduce radio 4.875 |
| Suspension | Leaf Spring(multi leaf) |
| Steering | Power steering |
| Brake | Dual-circuit drum braking system, air-cut brake. |
| Tyre | 7.50R16 6pcs |
| Other | Hoof piece of clearance automatic slack adjusters, Copper water tank |
Body
| Frame Structure | Semi-monocoque |
| Interior trim | Integrated module inner decoration(Outlet without reading light), side wall panels for fiberboard, a bar on roof |
| Door/Door pump | Driver's door, Center pneumatic folding passenger door,glass guardrail |
| Window / Windshield | Panoramic laminated front windshield, Aluminum sliding side windows, Black window frames, toughened glass |
| Rear view | Manual bracket-style rear view mirror/inner mirror |
| A/C | Top fixed refrigerating capacity 16000kcal/h |
| Defrost system | Water-heating |
| Audio-Video System | MP3 |
| Lamp | Front & Rear combination lamp, Rectangle dome light |
| Wiper | Opposite scrap wiper with syringe |
| Seats | passenger seat/ Adjustable driver seat/ seat belts |
| Floor leather | Bamboo plywood floor/Domestic antiskid floor leather |
| Lacquer | Solid lacquer |
| Others | Drive door pillaring a handle,a vice-drive door handle,Fire Extinguisher(4kgx1),Front windshield demi-shades,Folding side curtains,Electronic clock,tachograph ( including GPS ),Passenger door handle,Five - seat fence |
Our company was certified by the ISO/TS16949:2009 Quality Management System and 3C Authentication.
At present, the international business has covered more than 40 countries and regions.Products are exported to Middle East, South America, Africa, Russia and Europe and the United States and other high-end market, and has been in Chile, Hong Kong, Macao, Sudan, Syria and other countries and regions established after-sales service network, and 2011 in the united Arab emirates sign a sole agency.
With our service policy---support from maintainer,easily damaged parts and spare parts.Wuzhoulong warranty is to ensure excellent performance of Wuzhoulong bus.So service as bellow would be supplied:
1.According to the quality,certain senior maintainers(5 or above working experience) would be dispatched to the export country to take charge of maintenance at spot,technology training and aftersales service.
2.For the large quantity,a service network consisting of service station and spare parts warehouse would be established.
3.For every export bus,one set of easily damaged parts in value of RMB5000 for free and one list of parts and their prices for 3 years long would be supplied.
4.Each order would be supported with a series of free advertising things.Including well-illustrated catalogs,CDs and so on.
5.According to the policy on bus maintenance,maintenance for CBU is 80 thousand kilometers or one year,and the one for engine is 180 thousand kilometers or one year,subject to the one which reaches the requirement firstly.
