Detailed configuration of 50 seater CNG Coach Bus
Overall Parameter
| Over all length (mm) | 10990 |
| Over all width (mm) | 2500 |
| Over all height (mm) | 3580 |
| Wheelbase (mm) | 5350 |
| Front/rear over hang (mm) | 2350/3290 |
| Approach/departure angle (°) | 10/9 |
| Front/rear thread (mm) | 2020/1860 |
| Gross weight (kg) | 16500 |
| Rated passengers | 24-49 |
| Top speed (km/h) | ≤100 |
Engine Parameter
| Engine model | YC6L280N-50 |
| manufacture | Yuchai |
| Position/fuel | Rear / LNG |
| Type | Inline ,6 cylinders,turbocharger-intercoller,4 strokes,electronically controlled common rail fuel injection system |
| Max power (ps/r/min) | 280/2200rpm |
| Max. torque (N.m/ r/min) | 1100 N.m /1200~1700 rpm |
| Displacement | 8.424 L |
| Emission standard | Euro V |
Chassis Parameter
| Chassis Model | SX6115LM83T |
| Transmission | Qijiang QJS6-90,Flexible shaft remote control |
| Cultch | Single, dry, diaphragm spring, disc diameterφ395,hydraulic remote control, gas booster |
| Front axle | Dongfeng DENA,5.5T,disc brake |
| Driving axle | Dongfeng DENA,11T,ratio of speed 4.10,drum brake |
| Suspension | Spring 8,front 11rear |
| Steering | Power steering,, adjustable hand wheel,adjustable steering wheel,φ500 |
| Brake | Dual-circuit air brake with ECE standard, brake staff with front disc and rear drum, energy storage spring parking brake. |
| Gas tank | 450L |
| Tyre | 11R22.5-14PR , 6pcs |
| Battery/generator | 200Ah×2/150A 28V |
| Others | Copper tank,ABS,self adjusting arm. |
At present, the international business has covered more than 40 countries and regions.Products are exported to Middle East, South America, Africa, Russia and Europe and the United States and other high-end market, and has been in Chile, Hong Kong, Macao, Sudan, Syria and other countries and regions established after-sales service network, and 2011 in the united Arab emirates sign a sole agency.
With our service policy---support from maintainer,easily damaged parts and spare parts.Wuzhoulong warranty is to ensure excellent performance of Wuzhoulong bus.So service as bellow would be supplied:
1.According to the quality,certain senior maintainers(5 or above working experience) would be dispatched to the export country to take charge of maintenance at spot,technology training and aftersales service.
2.For the large quantity,a service network consisting of service station and spare parts warehouse would be established.
3.For every export bus,one set of easily damaged parts in value of RMB5000 for free and one list of parts and their prices for 3 years long would be supplied.
4.Each order would be supported with a series of free advertising things.Including well-illustrated catalogs,CDs and so on.
5.According to the policy on bus maintenance,maintenance for CBU is 80 thousand kilometers or one year,and the one for engine is 180 thousand kilometers or one year,subject to the one which reaches the requirement firstly.
