Detailed configuration of 11m Luxury Diesel Coach Configuration
Overall Parameter
| Overall length(mm) | 10990 |
| Overall width (mm) | 2500 |
| Overall height (mm) | 3600 |
| Wheelbase(mm) | 5350 |
| Front/Rear overhang (mm) | 2350/3290 |
| Approach/departure angle(°) | 10/9 |
| Front/Rear Tread(mm) | 2035/1860 |
| Gross Weight(kg) | 16500 |
| Rated Passengers | 24-49 |
| Top Speed (km/h) | ≤100 |
Engine Parameter
| Engine Model | YC6L280-42 |
| Engine man | Yuchai |
| Engine Position/Fuel | real / diesel |
| Type | Inline cylinders,6 strokes, High pressure common rail electric jet |
| Max Power (ps/r/min) | 280/2200rpm |
| Max Torque (N.m/ r/min) | 1100 N.m /1200~1700 rpm |
| Displacement(L) | 8.424 |
| Emission standard | Euro IV |
Chassis Parameter
| Chassis Mode/Manufacture | SX6114LM93 |
| Transmission | Qijiang QJS6-90,Three soft shaft long-distance manipulation |
| Clutch | single dry diaphragm springφ420, Hydraulic long-distance manipulation, air power |
| Front axle | 5.5T Dongfeng Dana, disc brake |
| Driving axle | 11T Dongfeng Dana, speed ratio 4.10, drum brake |
| Suspension | Air suspension |
| Steering | Power steering, double gimbal adjustable steering shaft, adjustable steering wheel, steering wheel diameterφ500 |
| Brake | Fit ECE standard dual-circuit air braking system, front disc brake and rear drum brake, Energy storage spring in car brake. |
| Tank | 400L |
| Tyre | 11R22.5-14PR, 6pcs |
| Charging generator | 200Ah×2/150A 28V |
| Others | Copper water tank with electromagnetic clutch fan, |
Body
| Frame Structure | Semi-monocoque |
| Interior trim | Molding soft interior trim, top board 5mm and fabric, PVC side plate, Molding duct with rack, Softening instrument desk. |
| Door/Door pump | Front & middle single pneumatic folding outside passenger door, telecontrol. |
| Window / Windshield | Panoramic laminated front windshield, adhesive side window |
| Rear view | Electric rabbit ears type rear view mirror |
| defrost system | Independent water-heating, 4 forced radiator. |
| Audio-Video System | MP3 |
| Lamp | Front & Rear combination lamp, Breakthrough type LED dome light, air flue with reading light. |
| Wiper | Opposite scrap wiper with syringe |
| Seats | 47+1+1luxury road bus seats, adjustable from left to right and front to rear , adjustable driver seat. |
| Floor leather | Resistant floor leather |
| Lacquer | Metallic lacquer |
| A/C | Independent dome style, cool capacity 28000kcal/h. |
| bin gate | Over type aluminum alloy bin gate. |
| handrail | There is a guide seat behind driver seat tailgate, middle passenger door flap, getting on handrail, softening foaming. |
| Others |
Electronic clock, Folding side curtains , front windshield , the driver window sunshade, Aluminum alloy wheel covers ( semi- cover ), Fire extinguisher, Warning triangle 1pcs , Security hammer with alarm function 4 pcs, Color reversing monitor,bus monitor(2 cameras), Driving recorder with GPS function, Engine compartment automatic fire extinguisher with alarm function, The 920B type with ventilator skylights 1 PCS |
Our company was certified by the ISO/TS16949:2009 Quality Management System and 3C Authentication.
At present, the international business has covered more than 40 countries and regions.Products are exported to Middle East, South America, Africa, Russia and Europe and the United States and other high-end market, and has been in Chile, Hong Kong, Macao, Sudan, Syria and other countries and regions established after-sales service network, and 2011 in the united Arab emirates sign a sole agency.
With our service policy---support from maintainer,easily damaged parts and spare parts.Wuzhoulong warranty is to ensure excellent performance of Wuzhoulong bus.So service as bellow would be supplied:
1.According to the quality,certain senior maintainers(5 or above working experience) would be dispatched to the export country to take charge of maintenance at spot,technology training and aftersales service.
2.For the large quantity,a service network consisting of service station and spare parts warehouse would be established.
3.For every export bus,one set of easily damaged parts in value of RMB5000 for free and one list of parts and their prices for 3 years long would be supplied.
4.Each order would be supported with a series of free advertising things.Including well-illustrated catalogs,CDs and so on.
5.According to the policy on bus maintenance,maintenance for CBU is 80 thousand kilometers or one year,and the one for engine is 180 thousand kilometers or one year,subject to the one which reaches the requirement firstly.
