Electronic instruments extension cable
Specifications
Instrument Thermocouple Wire Cable
Calibration: Type K J E T N RX/SX
Insulation: Fiberglass, PVC, FEP, PFA, Kapton, Silicon
J type Thermocouple Wire
Electronic instruments extension cable
We are the specialist on thermocouple wires, RTD cables and MI cables.
Production ability: 300, 000m/month.
Calibration: Type K, J, E, T, N, RX/SX.
Insulation material: Fiberglass, Kapton, Silicon rubber, Teflon (FEP, PFA), PVC.
Overbraided: Stainless steel.
Standard: ANSI/MC96.1, IEC584-3, JIS C1610, DIN 43714, BS 1843, NF C 42-323
Construction: Parallel conductor
Packing: 100m/roll to 1000m/roll
Type K, T, J thermocouple wire cable
Electronic instruments extension cable
Type |
Conductor |
Grade |
Working temperature |
Tolerance |
|
Insulation material |
deg.C |
||||
S |
Cu, Ni-Cu |
A |
PVC
Silicone:
Teflon
Fiberglass
Kapton |
-25~70C
-60~200C
-60~250C
-60~500C
-60-300C |
+ 3oC |
B |
+ 5oC |
||||
R |
Cu, Ni-Cu |
A |
+ 1.5oC |
||
B |
+ 2.5oC |
||||
K |
Cu, Ni-Cu/ Ni-Cr, Ni-Si |
A |
+ 1.5oC |
||
B |
+ 2.5oC |
||||
N |
Cu, Ni-Cu/ Ni-Cr, Ni-Si |
A |
+ 1.5oC |
||
B |
+ 2.5oC |
||||
E |
Ni-Cr,Ni-Cu |
A |
+ 1.5oC |
||
B |
+ 2.5oC |
||||
J |
Iron,Ni-Cu |
A |
+ 1.5oC |
||
B |
+ 2.5oC |
||||
T |
Cu, Ni-Cu |
A |
+ 0.5oC |
||
B |
+ 1oC |
||||
Electronic instruments extension cable
| 1.Package length | 200meres 305meter 500meter As customers requirement |
| 2.Package method | Rolls spool or coil |
| 3:Ship port | Shanghai, Shenzhen Ningbo Lianyungang Port. |
1: SAMPLE FREE BEFORE PRODUCE
2: ANY QUESTION WILL BE SOLVE IN 24 HOURS
3:PACKING ACORDING CLIENTS REQUIRE.
4:FILISHED GOODS ON TIME.
5 SERVICE CUSTOMERS IS OUR PURPOSE.
America Australia Mexico South Africa
UA Colombia Ukraine Ecuador England Germany (ERGE)
French Italy(ZOPPAS) Denmark(TRIAX)
Russia India Iran Uruguay Ireland etc.
Trade & Market
|
Main Markets: |
Oceania |
Total Annual Sales Volume: |
US$50 Million - US$100 Million |
Export Percentage: |
61% - 70% |
Product/Service (We Sell): |
Multilayer Fiberglass Braiding Wire,Mica Wie,Silicone Wire, Thermocouple Wire |
Number of Employees: |
101 - 200 People |
Our company is located in the history of Chinese history and culture of the ancient city, north of yangzhou, the famous hometown of charge - baoying, located in the beijing-hangzhou grand canal bank, beijing-shanghai expressway runs through north and south, convenient transportation, beautiful environment.
Our factory was founded in 2003, after 10 years of development, has a well-trained staff, factory employees 90 people, including management personnel 18 people, engineering technical personnel 20 people, the factory covers an area of 30000 square meters, factory building area of 10000 square meters.Achieve sales value of eighty million yuan, 2013 export value of $five million.Our factory in line with the service society, the enterprise concept of understanding the world, on the basis of quality and information, reputation and service for the guidelines, wholeheartedly welcome everywhere merchants to come to discuss cooperation, mutual benefit, hand in hand create a better future
Factory Size (ters): |
25,000-30,000 square meters |
Factory Location: |
Industrial Avenue,Industrial Center,Xiaji Town Baoying Country , Yangzhou Jiangsu,China |
|
Number of Production Lines: |
7 |
Number of R&D Staff: |
21 - 30 People |
Number of QC Staff: |
21 - 30 People |
Contract Manufacturing: |
OEM Service Offered Design Service Offered Buyer Label Offered |
