Help CenterUL1569 300V 200C PVC Braid High Temperature and High Voltage PVC Cable Wire
Related Products
-
UL10369 600V 200C PVC Braid High Temperature and High Voltage PVC Cable PricesUS$ 0.3 - 1.1MOQ: 1000 Meters -
UL1015 600V 200C PVC Braid High Temperature and High Voltage PVC Wire SupplierUS$ 0.3 - 1.1MOQ: 1000 Meters
-
UL1015 600V 200C PVC Braid High Temperature and High Voltage PVC Wire PricesUS$ 0.3 - 1.1MOQ: 1000 Meters
-
UL1569 300V 200C PVC Braid High Temperature and High Voltage PVC Wire CostUS$ 0.3 - 1.1MOQ: 1000 Meters
-
UL1007 300V 200C PVC Braid High Temperature and High Voltage PVC Cable ManufacturerUS$ 0.3 - 1.1MOQ: 1000 Meters
UL1569 300V 200C PVC Braid High Temperature and High Voltage PVC Cable Wire Feature:
Name: UL1569 300V 200C PVC Braid High Temperature and High Voltage PVC Cable Wire
Size: 26AWG~10AWG
Feature
Ratings: -60°C~+200°C, 300V
Conductors: Tinned copper, Copper
Insulation: PVC
Application
Used for internal wiring of household ovens, appliances, lighting fixtures and electronic equipment as high-teSpecificationmperature lead wire.
Specification
|
Size AWG |
Conductor Construction (No./mm) |
Insulation Thickness |
Diameter |
Max. Conductor Resistance (20℃) (Ω/km) |
20 |
26/0.16 |
≥0.38 |
1.7±0.2 |
37.4 |
18 |
16/0.254 |
1.9±0.2 |
23.5 |
|
16 |
26/0.254 |
2.3±0.2 |
14.6 |
|
14 |
41/0.254 |
2.6±0.2 |
8.96 |
|
12 |
65/0.254 |
3.1±0.2 |
5.64 |
|
10 |
105/0.254 |
3.8±0.2 |
3.54 |
Packing: 305m per roll or spool, carton packing or add wooden pads.
Shipping: transport by sea or by air.
As the customers requirements.
Port: Any port of China, Shanghai Port best.
1: Sample Free, Freight Collect!
2: OEM and ODM is welcome.
3: Within 1 week deliver sample, Bulb production within 3 weeks.
4: Good packing and design for carton.
5: Mobile on 24 hours for any question.
Universal and special Cables& Wires including UL High Temperature Wires, Multi-layers Fiber Glass Braided Wires, PTFE trapped Wires, Automobile Sensor Cables, HID Cables, High Voltage Wires for Auto etc.
Q: Are you manufactory or trading company?
A: We are the Manufactory specialized in all kinds of silicone electrical wire, high temperature electrical wire for 20 years. The wires we supply have obtained UL certificate.
Q: Can you show us your products test report?
A: Of course. You will have our products test report soft copy after asking. We send our product to do test every year. And our products test resort can pass RoHS & REACH standard.
Q: How can I get the samples?
A: You should pay for the transportation freight of samples and our samples’ cost, while the samples’ cost can be refundable after you place the order.
Q: How much the transportation freight of samples?
A: The freight depends on the weight and packing size and your area.
Q: How long can I expect to get the sample?
A: The samples will be ready for delivery in 5 days.The samples will be sent via express and arrive in 3-5 days.
Ps: More details please browse our website () or contact us.
