625 KVA SILENT DIESEL GENERATOR SETS

FOB Price

US$ 999 - 999,999 / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T L/C D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	Sudong
Model Number	SDDF500	Output Type	AC Three Phase
Speed	1500	Frequency	50
Rated Power	500	Rated Voltage	230/400/415/440
Rated Current	900

Product Description

Specifications

625 KVA SILENT DIESEL GENERATOR
1 shanghai engine
2 Great price and quality ratio
3 ISO9001:2008
4 Warranty: 1000 hour

625 KVA SILENT DIESEL GENERATOR SETS with shanghai diesel engine 12v135bzld

This genset is powered by Shanghai diesel engine, coupled with Sanbo alternator;

Stamford, Siemens and Marathon alternators are optional;

With Robust foot mounting, Reliable performance and Versatile configurations,

It’s your initial choice for inland power supply.

Any problem, please be free to contact me by skype: justinguo2006, Taizhou, China for instant communication!

Genset Feature

Our genset consists of Engine, Alternator, Foot-mounting, Control panel, Radiator, Air filter, Exhaust silencer, Elbow, Expansion joint, Battery, Shock absorber and Operation manual.

						Model Number:	SDDF500
						Prime Power:	500KW/625KVA
						Standby Power:	550KW/688KVA
						Rated Voltage:	230V/400V/415V/440V
						Rated Current:	900A
						Output Type:	AC 3 Phase
						Speed:	1500rpm
						Frequency:	50Hz
						Dimension (for reference):	*385016002000mm*
						Weight (for reference):	4500 kgs
						Accessory optional:	Fuel tank, Canopy, Soundproof enclosure

Diesel Engine Feature

Brand:	Dongfeng
Manufacturer:	Shanghai Diesel Engine Co., Ltd.
Model:	12V135BZLD1
Rated Power	555
Cyl. and arrangement:	V12
Bore/Stroke:	135/150mm
Aspiration:	Turbocharger, aftercooler
Configuration:	water cooled closed, 4-strike, direct injection
Governor:	Manual
Starting Method:	DC24V electric motor
Fuel Consumption:	198 g/kw.h
Accessory optional:	Governor: electric or servo Battery charger Engine coolant and oil heater Fuel-water separator

Alternator Feature

							Brand:	Sanbo
							Manufacturer:	Nanchang Kangfu Generators Technology Co., LTD
							Model:	KF-W4(.D)-500
							Electric capacity:	500KW/625KVA
							Voltage:	230V/400V/415V/440V
							Frequency:	50Hz
							Power Factor:	0.8 (lagging)
							Configuration:	Brushless, self-excited, AVR, 100% copper winding
							Connecting Type:	3 phase, 4 wires
							Insulation:	Class H
							Protection:	IP23
							Accessory optional:	PMG, Alternator space heater Anti-condensation heater

Control panel Feature

Brand: Smartgen
Microprocessor control module, with high stability and credibility
Monitoring and measuring operational parameters of the generator set
Indicating operation status, fault conditions, all parameters and alarms
Multiple protections, multiple parameters display like pressure, temp. etc.
Manual and automatic work mode selectable
Language optional of Chinese, English, Russian etc.
LED display, touch control
Real time clock display and log entries
Function optional: AMF, ATS, Paralleling, Remote control
