75KW Emergency Marine generator with Tier2-Diesel type engines-OEM generator Manufacturer-export to Africa
Kangmingsi Main/Harbor generator
Rated Power:30KW-800KW(38KVA-1000KVA);
Vlotage:50HZ,400V;Customized generatore:60HZ,440V and others are optional;
Electrical start,Spring start and air start are optional;
Engine monitor panel and genset control panel;
Powered by YUCHAI Engine coupled with Sanbo;Stamford,Siemens,Liandian,Marathon alternators are optional;
IMO Tier II Certificate;
CCS Approved.
75KW/93.75KVA 6BT5.9-GM100 Engine Technical Parameters
| Diesel Engine | |
| Brand | CUMMINS |
| Model | 6BT5.9-GM100 |
| Engine type | 6 cylinders in Line,4 stroke, direct injection |
| Aspiration | Turbocharged and water-to-air aftercooled |
| Rotating speed | 1500 RPM |
| Engine cooling system | Water-cooled |
| Speed governing system | Electronic speed governor |
| Starting method | By 24V batteries |
| Engine filter system | Dry type air filter ,fuel filter, oil filter, water filter |
| Displacement(L) | 14 |
| Bore×Stroke(mm) | 102×120 |
| Compression ratio | 17.5:1 |
| 100% Load fuel consumption (g/kw.h) | ≤204 |
| Lube capacity(L) | 16.4 |
Marathon Alternator Technical Data
| Alternator model | Marathon |
| Alternator manufacturer | MP-H-75-4 |
| Service Duty | S1 |
| Rated output prime power | 75 KW/93.75KVA |
| Rated speed | 1500 RPM |
| Rated frequency | 50 Hz |
| Current(A) | 135 |
| Phase | 3 |
| Connect | Y |
| Rated voltage | 400 V(Available with customer requirements) |
| Power factor | 0.8 |
| Exc.volt(V) | 40 |
| Exc.curr(A) | 1.7 |
| Insulation grade | H/H |
| Protection grade | IP23 |
Product Advantages:
1. Diesel genset comply with CCS,BV,ABS,DNV,GL,RINA,RS.
2. Passed through Certifications:ISO9001,CE
3. Professional engineers and skilled technicals,sales teams.
4. Complete production procedures, strict test center, good package
5. Warranty: Running for one year
6. Steady relationships with engine and alternators’ supplier both domestic and global.
7. Excellent after sale service.
6BT5.9GM100 Product show
Genset Spares show
Company Introductions
Sudong Power is a specialist company in design and manufacture of generator sets.For over 11 years' of development,Sudong power has earned the reputation in the market to supply power solutions for various applications with a broad range in power capacities.
Our goal is o sustain at the forefront of domestic and global market for power solutions in an upgrading power range in terms of perofrmance,quality and services.SUDONG POWER is trading forward to this goal with steady steps.
Company Products Show
Certificates and Factory show
Sudong Power your reliable partner for generator set.
Any more welcome to contact us.
