LZZ series low cost variable area 4-20ma digital water flow meter type
Diameter:15-150mm
Technical parameter:
Measurement range: water:2.5~100000L/h
Gas:0.07~3000 m³/h
Range ratio: 10:1(Dwithin100mm)
5:1(DN≥100mm)
Accuracy: standard, 1.5,special:1.0
Maximum of presure: DN15. DN25. DN40. DN50- 4.0Mpa
DN80, DN100. DN150- 1.6Mpa
Medium temperature: ordinary, -40 º C- 100 º C
High temperature model:--80 º C-250 º C
Liner F46fluoroplastic:-40 º C-80 º C, PTFE-10 º C-120 º C
Ambient temperature: pointer model: -40 º C-65 º C
Intelligent model: -25 º C-65 º C
Connection: flanged .thread, tri-clamp.
Electric interface: M20x1.5
Protection class: IP65
Explosion-proof class: intrinsically safe, ExibIICT4, Explosion-proof: ExdIIBT4
Medium viscosity:DN≤5Mpa*s DN25-150≤250 Mpa*s
Power supply: 3.6VDC 2 wires, 4-20mA
Pipe material: 304 stainless steel, 316 stainless steel , 304 or 316L liner material PTFE or F46
Float material: 304 or 316L(stainless steel) ,PTFE or F46
Megnetism Fiter
If there are some ferromagnetism granule in the medium, a magnetism filiter must be installed in the entrance of the flowmeter .There are some magnetism sticks whini hch are ranked in helical in the magnetism filter, it can cutt down pressure loss maxinunly.Every magnetism stick is coverer with PTPE, prevent from corresiom by medium.
I type:Flange conneetion, height :100mm
IItype :Inpacted installation, heigh:50mm
Antivibrator(gas)
If the flow (pressure)in the entrance of the flow meter is unsteaediness.in order to ensure that the flowmeter can work steadily and credily for long time when we measure clean gas we can install an antivibrator with high tech manufacture .On the measure component.
It is unfit for using an antivibrator if there are some tiny granule or dust in the gas .Under this civcumstance , it is request the pressure in the entrance is bigger than 5times of flowmeters pressure loss so we can ensure that flowmeter can work nomally. For diameter D15, we can level off the flow by pressure adjuster.
Technical parameters of LZ-series flowmeter
|
Anticorrosion Diameter (DN mm) |
Normal Diameter (DN mm) |
Measure Range |
Maximum Pressure Loss |
||
Air20°Cm3/h |
Waterl/h |
Air(Kpa) |
Water MPa |
||
|
15 |
15 |
0.05-0.5 |
1.6-16 |
7.0 |
6.4 |
0.07-0.7 |
2.5-25 |
7.1 |
6.5 |
||
0.11-1.1 |
4.0-40 |
7.2 |
6.5 |
||
0.18-1.8 |
6.0-60 |
7.3 |
6.6 |
||
0.28-2.8 |
10-100 |
7.5 |
6.6 |
||
0.40-4.0 |
16-160 |
8.0 |
6.8 |
||
0.70-7.0 |
25-250 |
10.8 |
7.2 |
||
1.00-10 |
40-400 |
10 |
8.6 |
||
1.60-16 |
60-600 |
14 |
11.1 |
||
|
80-800 |
|
14 |
||
25 |
25 |
3.00-30 |
100-1000 |
7.7 |
7.0 |
4.50-45 |
160-1600 |
8.58 |
8.0 |
||
7.00-70 |
250-2500 |
12 |
10.8 |
||
11-110 |
400-4000 |
19 |
15.8 |
||
|
500-5000 |
|
16.2 |
||
50 |
50 |
18-180 |
600-6000 |
8.6 |
8.1 |
25-250 |
1000-10000 |
10.4 |
11 |
||
40-400 |
1600-16000 |
12.6 |
17 |
||
80 |
80 |
50-500 |
2000-20000 |
15.5 |
6.3 |
75-750 |
2500-25000 |
17.2 |
8.1 |
||
100 |
100 |
100-1000 |
4000-40000 |
|
9.5 |
160-1600 |
6000-60000 |
|
10 |
||
125 |
125 |
250-2500 |
8000-80000 |
|
16 |
|
10000-100000 |
|
20 |
||
150 |
150 |
300-3000 |
12-120m3/h |
|
20 |
400-4000 |
15-150m3/h |
|
25 |
||
Yuyao Kingtai Instrument Co.,Ltd specializes in the research and development,manufacture.sales and services of industry instruments. our main products are flowmeter,pressure gauge and solenoid valve.we are one of the biggest manufaccturer of flowmeter in china.we have establish friendly and long term relationshs with famous corporation in the world.
We win our good repulation among customers, our goods passed though ISO9001:2008.We are committed to producing products with high quality and new technology to meet the demands of our customers.
We have a professional production team to ensure the quality and safety.adcanced equipment to make production more fast and efficient.
Warehouse
Certificate
1. Professional and patient pre-sale and after-sale service on our products;
2. Stable quality and reasonable price for you to gain long term cooperation;
3. OEM & ODM service for quantity orders;
4. Sample orders welcomed for quality test;
1.Why do you order from the KINGTAI?
The KINGTAI company can provide you competitive price.
2.What about the delivery time?
Honestly, it depends on the order quantity and the season you place the order .for bulk order which production lead time is within 1~3 weeks.Generally speaking, small QTY are in stock
3.What is your payment method?
T/T, Western Union, Moneygram, Paypal are available for us
4.Can you make my logo on product?
Of course! we are factory,we supply OEM ,You only need provide us your original logo file or clear picture, so we can make it.
5. How to delivery ?
Shipped by express for sample order and small order, express include DHL, UPS, TNT,, EMS, etc. Shipped by sea or by air for bulk order.
6.What is your terms of delivery?
We accept EXW, FOB, CIF etc. You can choose the one which is the most convenient or cost effective for you.
