Help CenterPCB-28001 Powder Coating Spray Booth
Related Products
-
PCB-25001(D) Electrostatic Powder Coating BoothUS$ 6,500 - 10,000MOQ: 1 Set -
PCB-PCL Powder Coating LineUS$ 1,000 - 100,000MOQ: 1 Set
-
PCB-25001(D) Powder Coating Spray Booth CabineUS$ 1 - 10,000MOQ: 1 Set
-
PCB-25001(D) Powder Coating Application CabineUS$ 7,000 - 9,000MOQ: 1 Set
-
PCB-28001 Powder Coating Spray BoothUS$ 2,500 - 5,000MOQ: 1 Set
Furniture use available...
Professional design
It is economical, easy to operate.
Reliable and good quality and competitive price
1,high-efficiency powder recycle
2,low energy consumption
3,convenient color change
4,excellent quality
5,competitive price
Type/Name |
Powder coating booth |
|
Brand |
King |
|
Model no. |
PCB-28001 |
|
Production Capacity |
100 SETS PER MONTH |
|
Voltage |
AS REQUIRED |
|
Power |
AS REQUIRED |
|
Place of Origin |
CHINA, SHANDONG |
|
Dimension(mm) |
2800(L)*1150(W)*1700(H) |
|
Cabin Material |
Made of cold-plates, powder coated. |
|
Powder recovery system |
Dust filter cartridge |
4pcs |
Solenoid valve |
4pcs |
|
Circulation system |
1 set of centrifugal blower, motor 5.5KW, air flow 4000~6800 m3/h |
|
Pulse Programmed control system |
1 set |
|
Weight |
1200KGS |
|
Warranty |
12 MONTHS |
|
Delivery time |
Within 10 days upon deposit |
|
Packaging |
Proper packing suitable for container loading |
|
Application |
Used for two work position |
|
1. we are factory manufacturer;
2. the company got ISO9001 certificate;
3. the products get CE certificate;
4. the burner both are italy RIELLO burner;
5. over 20 years experience;
6. have export experience;
7. we have stock for the goods;
8. the gun have 3-year warranty period.
The advantages for the KING powder coating spray booth
1.Suitable for coating large items
2.Small set-up area
3.Sturdy industrial design
4.Integrated powder recovery
5.Floor mounted, no castors
6.Connection for gun controller
7.Illumination provided
8.High suction performance of 8000 m3/h /h
9.Suitable for operation with a conveyor system
10. The option of pre- and after coating stands
11. This creates a uniform air speed and good coating
12. Compact, with no supporting frames and no pit excavation.
13.Automatic filter cleaning: Interval control for filter pulse duration
14. High application effectiveness due to low booth floor and vertical airflow
15. The floor of the booth can be walked on, facilitating cleaning and maintenance work
16. Excellent illumination of the booth and manual coating stands thanks to booth lighting integrated into the roof
17. No powder deposits thanks to optimization of the air flows in the extraction channels
18. Less space required with higher performance and flexibility. The booth achieves the best utilize of space so far
in the field of plastic booths. The result is a greater production capacity on a smaller area, and with it a distinctly
higher return on investment.
19. Rectangular booth shape - also suited for horizontal gun arrangement. No powder deposits on the floor - super fast booth cleaning. Economical use of material. The KING booth combines these benefits.
powder coating booth
Application: used for the powder coating and line, plant
Shipping: can ship to any port from QINGDAO PORT by sea.
Payment methods: escrow, T/T, L/C
Packing: proper packing suitable for container loading
we supply following equipment:
1. liquid paint coating equipment
1.1 Car spray&baking room system
1.2 Bus spray&baking room system
1.3 Furnitue spray&baking room system
1.4 Industrial painting&baking room system
1.5 High temperature painting&baking room system
1.6 Customized spray&bake booth. Offer car spray baking booth accossories
2. electrostatic powder coating equipment
2.1 electrostatic powder coating spray gun machine(manual/auto)
2.2 electrostatic powder coating application spray booth/cabin(manual/auto)
2.3 electrostatic powder coating curing oven/furnace(batch type/bridge type/tunnel type)
2.4 electrostatic powder coating conveyor line(manual/semi-auto/fully auto)
2.5 electrostatic powder coating sieve machine
2.6 electrostatic powder coating reciprocating machine
2.7 electrostatic powder coating plant
1. Founded year:1988.
2. Registered capital:three million RMB
3. Legal representative:Yuhu Liu
4. Nature of company:manufacture
5. Design team:8engineers,R&D
6. Scale:medium
7. Employee number: less than 100
8. Main product: liquid paint spray equipment and powder coating application equipment
9. Sales volume: over 10million RMB last year
10. After-sales service: Provide lifelong technical consultrant and the design drawings and the user manual of the products.
11. Certificate: CE, ISO 9001
If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.
