Specifications
1, using imported compressors, pumps, super cooling and long life.2, high-efficiency evaporator and condenser, heat exchange
Water cooled industrial chiller
Specifications:
Model |
MCA-5 |
MCA-10 |
MCA-15 |
MCA-20 |
MCA -25 |
MCA -30 |
MCA -40 |
|
Refrigerating capacity |
KW |
15 |
29.7 |
44.1 |
58.6 |
69 |
86.2 |
117.2 |
Kcal/h |
12900 |
25600 |
38000 |
50390 |
59340 |
74100 |
100790 |
|
Input power |
3- phase 380V 50HZ |
|||||||
Compressor |
Type |
All-closed vorticity/all-closed piston/semi-closed/screw |
||||||
Input power(kw) |
3.75 |
7.5 |
11 |
15 |
18.75 |
22.5 |
30 |
|
Built-in freeze water pump |
Power(kw) |
0.75 |
1.5 |
1.5 |
2.25 |
2.25 |
2.25 |
3.75 |
Condensor |
Type |
Efficient copper tube cover aluminium |
||||||
Fan Type |
Low noise outer rotor metal blower |
|||||||
Evaporator |
type |
Stainless steel water tank plate copper tube |
||||||
Dia of outlet and inlet(INCH) |
4×(1/2) |
1.5 |
1.5 |
2 |
2 |
2 |
3 |
|
Water tank capacity(L) |
50 |
120 |
180 |
250 |
300 |
350 |
450 |
|
Refrigerant |
Type |
R-22 |
||||||
Flow control |
Caloric power expansion valve |
|||||||
Magnetic valve |
Castol Italy castol |
|||||||
Filter |
“ALCO” America” ALCO” |
|||||||
Electric material |
Taiwan Taian technology |
|||||||
Controller |
Micro computer digital display control. Degree of precision ±°C |
|||||||
Temperature range |
3°C------40°C |
|||||||
Protective device |
High/low pressure protective switch, phase failure protection, overload protective switch, antifreeze switch, time delay protection, over-temperature protection, over-current protection |
|||||||
Dimension(cm) |
125×58×124 |
162×85×160 |
182×93×165 |
235×90×165 |
235×93×170 |
240×93×170 |
245×93×175 |
|
Guarantee: 1 Year in common using condition (except damageable and aitificial)
Repair: 1) We provide technical guidance all life.
2) Within the guarantee period, we will offer customers spare parts free of charge if spare part is broken and the problems caused by our quality. (The freight is for buyer's account)
Installation:
We provide technical guidance, and also we can offer our technical engineer to buyer's factory for installation If buyers require. Ticket, board and lodging and some related local expenses in Buyer's country for buyer's account.
1 Plywood case and film
2 According to customer's requires
GuangzhouJiayin Machinery Pte.,Ltd.(Primitive name:Guangzhou Mikasa Machinery Pte., Ltd) is one of the pioneers in auxiliary plastic forming equipment industry in China,specializing in research,design,manufacture and distribution of and service for such equipment with the technology andexperience accumulated about 30 years.
Our products include crushers,grinders,rubber cutters,dryers,dehumidifiers,suction machines,color mixers,mould temperature controllers,water chillers,color master batch propor.wire recycling machine..more
