Help CenterFull-auto Cable Separater
Related Products
Specifications
1.recycling copper from cable/ copper wire2.Full-auto copper wire crusher
3.Copper wire crusher with good adaptability
Main equipments and functions:
1,No.1 cutting machine, it needs the operator to put the waste wires into machine. Although this step must be operated manually, it has the features like easy to operate and high output.
2,Magnetic conveyer: it moves the waste wire from No.1 cutting machine to No.2 machine, and the magnet is equipped at the top of the it; when the No.2 pulverizer is full, the conveyer will stop working till the No.2 machine gets right.
3,No.2 pulverizer: it is a device which is used for crushing the 2~3cm wire from No.1 pulverizer. This machine can crush the foreign body on external surface and separate the external rubber with copper completely. Additionally, the filtering network fixed at the bottom of machine is used for controlling the processing speed and output for different wires, and it is suitable for processing the cable from thinner one like hair to thicker one like power cable when it change the filter network. The pulverizing chamber can be operated by oil pressure system, what is more, it is easier to repair and change the blade.
4,Blower- move the crushed materials from No.2 pulverizer to sorter by wind wave and pressure.
5,Sorter—as a core part, it is used to separate the copper and external rubber, though the structure is complex, it is easy to operate.
6,Cloth dust collector—this device is used for collecting the dust produced in sorter through blower, there are 12 filtration
Working Video:
/v_show/id_XMTAzNzMwNzUy.html
/v_show/id_XMzgxOTgyMjI4.html
/v_show/id_XMzcwNjE1MzUy.html
/v_show/id_XNDY0MjkzOTcy.html
