Multifunction Bottom And Side Seal Bag Making Machine (Diaper Bag/Garment Bag Series)
* Suitable for PE,CPP,PP,PVC film bag side sealing.
* Adopts Japanese servo motor control. Taiwan frequency converter speed control. TL50 photocells tracking. High quality conveyer belt and Taiwan frequency converter speed control in conveying device.
* High quality alloy steel knife. Heat resisting and deformation resistance. Sealing bar made of heat resistance silica gel.
* Feeding frame automatic correction. Magnetic powder brake tension control and sheet film folder.
* Suitable for producing:
*European style paper bag diaper
*hidden tape portable diaper bag
*drawing rope garbage bag
*zipper garment bag
*double inflexed handbag(EVA environmental protection bag)
* Supporting functions:
*Round air hole and hand hole
*dotted line easy-tear mouth
*PE tube film rupture device
*ultrasonic reinforce function.
Model |
MXBF-700 |
MXBF-800 |
MXBF-1000 |
|
Max.Bag Width |
700mm |
800mm |
1000mm |
|
Max.Bag Length |
60~700mm |
65-700mm |
65-800mm |
|
Machine speed |
(2types) diaper bag |
30-60pcs/min |
30-60pcs/min |
30-50pcs/min |
drawing rope bag |
30-60pcs/min |
30-70pcs0/min |
30-70pcs/min |
|
zipper bag |
30-70pcs/min |
30-70pcs/min |
30-70pcs/min |
|
double inflexed bag |
30-80pcs/min |
30-80pcs/min |
30-80pcs/min |
|
Tolerance |
±1 |
±1 |
±1 |
|
Power Required |
7.5kw |
8.5kw |
10.5kw |
|
Machine size |
1200*1350*1820mm |
1200*1450*1820mm |
1200*1650*1820mm |
|
Machine N.W |
2000kg |
2200kg |
2400kg |
|
Guangdong Maoxin Electrical Machinery Co.,Ltd.has been set up since 2001 in Jinping Industrial Park, Shantou city, where all the leading machenics domestic and international companies for export has been gathered, producing, packaging and servicing to meet all the needs of clients.
For machinery equipments, we mostly supply domestic and foreign equipments with the following main products:
* Film blowing machines,
* Packaging machines,
* Printing machines,
* Bag cutting machines,
* Cup making machines,
* Complex machine,
* Sheet machines, and other computer accessories ….
Providing a good background in Guangdong market as well as a good base for international market, with the philosophy of “ human as the leader, technology as the priority” and a commitment toward quality and further business to create real values to clients, Maoxin hopes to have opportunities to cooperate with you for a brighter future!
Shantou Corporation:The Second End of Chaoyang Road, Jinyuan Industrial Zone, Jinping Area, Shantou City, Guangdong Province (At the Junction with Jinfeng Road).
Tel:0086-754-88881005
Fax:0086-754-88215671
Http:
E-mail:alexzhang(at)
Vietnam Office: 304 Room, 34T Building, Trunghoa Nhan Chinh Area, CayGiay District, Hanoi city, Vietnam.
Tel:0084-975697998
Fax:0084-2462810457
Skype:dongocvn87
Http:maoxin.vn
E-mail:mxvn68(at)
Multifunction Bottom And Side Seal Bag Making Machine (Diaper Bag/Garment Bag Series)
