Specifications
Polycarbonate-2UV Solid Sheet co-extruded with the protective layer of UV on each two sides,Polycarbonate-2UV is made of Bayer Makrolon polycarbonate resin, Ketelong 2UV PC Solid Sheet is co-extruded with the protective layer of UV on each two sides, which makes the sheet have excellent aging resistance and outstanding impact resistance so as to be widely used in the architecture industry.
Ketelong 2UV PC Solid Sheet is Convenient processing, with a high design freedom. Be processed into cold-formed for a perfect arc shape, for the skylights, pedestrian bridges, barrel vault, etc. also can be hot forming processed into a variety of complex geometry.
Product features:
Transmitting
Ketelong 2UV PC Solid Sheet’s transparent plate light transmission rate is up to 88%
Impact resistance
The impact strength of Ketelong 2UV PC Solid Sheet is 250-300 times of ordinary glass, is of 30 times to the same thickness of acrylic plate.
Simulated hail impact test: In the simulated hail impact test machine to simulate hail impact, will be a diameter of 20mm (weight 4.8g) of nylon balls to 21m / s speed of the launch of the model to observe the extent of damage model and found that glass and acrylic forces have been ruptured or broken, while the Ketelong 2UV PC Solid Sheets are not broken.The hail to the diameter of 20mm ,the ultimate speeds is up to 21m / s in real life.
Aging resistance
The two sides with 50um UV protective layers can block ultraviolet rays pass through Ketelong 2UV PC Solid Sheet, which ensures the sheet for better aging resistanve. Comparing with the sheet of one single UV side, the 2UV sheet can face towards the sun with each side, which make the installment mistakes decrease to the least.
Light weight
Ketelong 2UV PC Solid Sheet’s proportion is only half of ordinary glass, savings costs in transport, unloading, installation, and support framework.
Fire-retardant
Ketelong 2UV PC Solid Sheet’s Self-ignition is 580 ° C, self-extinguishing after away from the fire. Combustion does not produce toxic gases, not fuel the fire from spreading, according to national standard GB8624-1997and is flame retardant Grade B1.
Flexible
Ketelong 2UV PC Solid Sheet may be in accordance with the design on-site use of cold-formed, installation into the arched, semi-circular roof and windows. Minimum bend radius for the introduction of plate thickness of 100 times, also can be hot bending.
Sound insulation
Ketelong 2UV PC Solid Sheet’s sound insulation is obvious effects than the same thickness of glass and Acrylic panels for better sound insulation in the international arena, and is the prefer choice material for highway noise barriers. For example: 6mm Ketelong 2UV PC Solid Sheet’s sound insulation is 29dB.
Energy-saving
Ketelong 2UV PC Solid Sheet makes Cool in the summer, and Warm in the winter, thermal insulation higher 7% -25% than the same glass .
Adapt to the larger temperature difference
Ketelong 2UV PC Solid Sheet does not occur the cold crisp in the -40 ° C and in the 120 ° C without softening, in the harsh environment of its Mechanics, mechanical properties, etc. have no significant changed.
Hot formability
Ketelong 2UV PC Solid Sheet is easy to shape, so in accordance with a variety of designs to meet your molding requirements, and has excellent performance.
Guarantee
Ketelong 2UV PC Solid Sheet to provide 10 years quality warrant.
Typical performance indicators:
Standard thickness
0.8mm,1.0mm,1.2mm,1.5mm,2mm,3mm,4mm,4.5mm,6mm,8mm &10mm.
Standard width
1220mm,1560mm,1820mm,2100mm (Can be customized according to customer requirements of any width less than 2100mm)
Standard Size
Sheets: 1220 X2440mm
Coil: Thickness<4.5mm 30~50m/roll
Color
Clear, blue, green, brown, opal
Application:
•Clearstory in residence
•The lighting roof for industrial workshops and storehouses
•Passageways
•Corridors
•Parking sheds
•Stadium
•Sound-insulation walls on expressways
•Swimming-pools
•Greenhouse
•Interior lighting
