Help CenterZYY Specific Gravity Separator
Related Products
-
Food Grade Stainless Steel Circular Flour Vibrating ScreenUS$ 1,000 - 100,000MOQ: 1 Set -
ZYD High Frequency and Quality Coffee Screening Machinen With CE&ISOUS$ 1,000 - 5,000MOQ: 1 Set
-
ZYQW China Xxnx Hot Mini Horizontal Airflow Vibrating Screen ClassifierUS$ 800 - 1,500MOQ: 1 Set
-
ZYZP China Xxnx Hot Mini Direct Discharging Vibrating Screen ClassifierUS$ 1,000 - 1,500MOQ: 1 Set
-
China Xxnx Hot Mini Circular Lab Testing Vibrating Screen ClassifierUS$ 800 - 1,500MOQ: 1 Set
ZYY specific gravity separator is an efficient sieving machine which is designed to meet the large output, high-density sieving of the manufacturers. The simplest sieving method is using your hands with the staring of your eyes. Tumbler sieving machine is the mechanical simulation for this, it is the most effective principle which takes the most effective simulation of the artificial sieving movement (sieving precision, efficiency, service life is 5-10 times than common cylinder sieve), for the processing of all the fine and ultra-fine powder and special materials, particularly suitable for materials which are difficult to classify.
Applied Field
Chemical, food and spices, plastics, mining, medicine, wood and plywood, metallurgy, rubber, fodder, fertilizer, sugar, salt, renewable industry.
Feature
- Up to 5 times outlet compared than common sieving machine.
- At most 6 Level separation.
- Sieving efficiency is as high as 90% -95%.
- When using the silicone rubber balls, ultrasonic and other high-performance mesh- cleaning device system, the sieve aperture will not be blocked.
- Enclosed cleaning dust, safe operation; the acceleration is 4.5 times lower than common vibrating screen.
- Noise <75 dB. Re-optimization is balanced, ground-based dynamic load is low.
Technical Parameter
Model |
ZYY-600 |
ZYY-1000 |
ZYY-1200 |
ZYY-1600 |
ZYY-2000 |
ZYY-2400 |
ZYY-2600 |
Diameter(mm) |
600 |
1000 |
1200 |
1600 |
2000 |
2400 |
2600 |
Sieving area(m²) |
0.29 |
0.71 |
1.11 |
1.83 |
2.62 |
3.63 |
5.31 |
Spatial requirement |
0.4 |
1.2 |
1.6 |
2.5 |
3.6 |
5.2 |
6.8 |
Max sieve layer(s) |
5 |
5 |
5 |
5 |
5 |
5 |
5 |
Power Consumption(Kw) |
0.25 |
1.5 |
2.2 |
2.2 |
2.2 |
5.5 |
5.5 |
Filter accessories |
2 layers |
2 layers |
2 layers |
1 layer |
1 layer |
1 layer |
1 layer |
ZYY specific gravity separator 's outlet .
ZYY specific gravity separator 's motor .
