PE iron ore mining process stone crusher
Description
Mini jaw crusher for metal is a kind of heavy duty machine which can crush materials into even granularity.
This stone crushing machine has the characteristics of high reduction ratio, high productivity, simple structure,
and reliable performance, etc. It is convenient to maintain and practical to use.
Our Jaw crushers can be used in mining industry, metallurgical industry, construction, smelting,
road building, chemical industry, and other fields, for crushing various materials whose compressive strength
is not more than 320 MPa.
Working Principle
Toggle plate is also used to guarantee the security. Jaw crusher uses electric motor as the motive power.
Eccentric shaft is driven by triangle belt and genea wheel, which makes movable jaw make reciprocating motion
according to the desired trajectory. Then, materials in crushing chamber (consists of fixed jaw plate, movable jaw
plate and edge plate) are crushed and the finished materials are discharged from discharging hole.
Technical Parameters:
|
Mode (mm) |
Biggest particle size(mm) |
Exit adjustable scale(mm) |
Output capacity (t/h) |
Power (Kw) |
Weight (t) |
PE250X400 |
210 |
20-70 |
5-20 |
15 |
1.9 |
PE400X600 |
340 |
40-100 |
15-40 |
30 |
5.4 |
PE500X700 |
420 |
50-100 |
20-70 |
55 |
8.9 |
PE600X900 |
520 |
60-150 |
50-150 |
75 |
16.5 |
PE750X1060 |
630 |
80-140 |
50-180 |
110 |
28 |
PE800X1060 |
640 |
120-200 |
130-230 |
110 |
31 |
PE900X1200 |
750 |
140-220 |
140-260 |
110 |
48 |
PE1000X1200 |
850 |
190-270 |
300-350 |
110 |
53 |
Features
1. Crushing chamber is deep and has no dead space, which helps improve the feeding capacity and productivity.
2. Our jaw crusher has high reduction ratio and the crushed materials are of the even granularity.
3. Adjustment device of gasket type discharging opening is reliable and convenient to use. The discharging opening has wide adjusting range. This can increase the flexibility of our equipment.
4. Lubrication system is safe and reliable. Accessories are convenient to replace, and little maintenance is needed.
5. Jaw crusher has simple structure, reliable performance and low operating cost.
6. Jaw crusher is a kind of energy saving equipment. Single machine can save 15% ~ 30% energy and whole system saves more than doubled energy.
7. Discharging opening has large adjusting range, so your different requirements can be satisfied.
8. Low noise and little dust.
Zhenying brand jaw crusher machine
Different colour for jaw crusher according to our customer.
This tyre jaw crusher machinewill be dispatched to South Africa.
If you want to know more information,please contact whatsapp: +8613781997628.
This quarry primary stone jaw crusher machine export to Peru.
