Flexible Portable LCD Screen Tft Display

Flexible Portable LCD Screen Tft Display thumbnail-1
Flexible Portable LCD Screen Tft Display thumbnail-2
Flexible Portable LCD Screen Tft Display thumbnail-3
Flexible Portable LCD Screen Tft Display thumbnail-4
Flexible Portable LCD Screen Tft Display thumbnail-5
Flexible Portable LCD Screen Tft Display photo-1
Flexible Portable LCD Screen Tft Display photo-2
Flexible Portable LCD Screen Tft Display photo-3
Flexible Portable LCD Screen Tft Display photo-4
Flexible Portable LCD Screen Tft Display photo-5
US$ 1.00 - 1.00 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
INNOLUX
Model Number:
AT043TN24 V.1
Contact Supplier Request Quote Chat Now
Zhejiang Qiyang Intelligent Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name INNOLUX
Model Number AT043TN24 V.1
Usage Other
Tube Chip Color Other
Display Function Other
Pixels Other
Screen Dimension 4.3 inches

Specifications



4.3' industrial TFT-LCD
1.Panel Size: 4.3 inches
2.Resolution: 480x272
3.Display Scale: 16:9
4.Panel Type: a-Si TFT



 Feature









<1>Brand: INNOLUX
<2> Product Model: AT043TN24 V.1
<3>Panel Size: 4.3 inches
<4>Resolution: 480x272
<5>Display Scale: 16:9
<6>Brightness: 400 cd/m2
<7>Contrast Ratio: 500:1(transmission)
<8>Panel Type: a-Si TFT-LCD
<9>Signal Interface: RGB(1 ch,8-bit)
<10> Features: matt surface; up/down, left/right flip show; white LED backlighting

  4.3'TFT-LCD  With touch panel

industrial TFT-LCD Display 480*R.G.B*272 16:9



Flexible portable LCD screen tft display Structural Parameters

• Working Temperature:    -10°C ~ 60°C

• Storage Temperature:    -20°C ~ 70°C

• Panel Weight:    62g

• Surface Treatment:    matt surface

• Resolution:    480(RGB) x 272 (WQVGA)

• Aspect Ratio:    16:9

• Pixel Arrangement:    R.G.B

• Pixel Pitch:    0.198x0.198

• Display Area:    95.04x53.856 mm

• Visual Area:    98.70x57.50 mm

• Size:    105.5x67.2 mm

• Thickness:    4.05 mm

• Touch Screen:    with touch screen




Flexible portable LCD screen tft display Optical Property

• Display Mode:    TN, Normally White Display, transmittance

• Brightness:    400 cd/m2

• Contrast Ratio:    500 :1 (transmission)

• Display Color:    16.7M(8bit)

• Response Time:    10/15(Tr/Td) ms

• Viewing Angle:    70/70/50/70 (up/down/left/right)

• Optimal Viewing Angle:    6 o'clock

• White Field Chroma:    X:0.310; Y:0.330

• Scan Frequency:    1.33/1.43(Typ./Max.)(9points)

• Inversion Scanning:    NO

• Power Consumption:    848mW

• Kind of Signal Interface:    40 pins 0.5mm spacing FPC

• Signal Type:    Parallel RGB(1ch,8bit)

• Signal Interface Voltage:    3.3V

• Signal Interface Current:    17/25mA(Typ./Max.)

• Signal Interface Power:    56mW (Typ.)

• Backlight Tube Position:    side into type light source

• Lamp Type:    WLED

• Lamp Life:    20,000 (h)

• Voltage of Lamp:    19.8V(Typ.)

• Current of Lamp:    40mA(Typ.)

Why Qiyangtech?
1.Technical Support for lifetime.
2.Open Source.
3.Customisation Service.
4.Supply stably and chronically.

Wanna get a free Flexible portable LCD screen tft display catalogue?
Wanna get an accurate price of Flexible portable LCD screen tft display?
Wanna get information of same series products of Flexible portable LCD screen tft display?

Contact us NOW!
