Tablet PC 7'' touch screen Human Machine Interface
- 100000 Piece / Pieces per Month
- Shanghai or Ningbo
- T/T L/C D/P D/A Credit Card PayPal
- 60W UL CE LED Canopy Lamp with aluminum frame Ex-factory price from Shenzhen
- 80W Energy-Saving Gas Station LED Canopy Lamp hot sale from Shenzhen
- 60W UL CE Energy Saving LED Canopy Lamp with 3 years warranty from Shenzhen
- 2014 new design, led flood light, led Gas Station Lamp, LED canopy light 100w
- Led flood light, led Gas Station Lamp, LED canopy light 100w
- 120W High power cree led canopy lamp Wholesale from Shenzhen for gas staton
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | QY | Model Number: | SHMI-701H |
Screen Dimension: | 7'' |
Product Description
Human Machine Interface Quick Details
- Place of Origin: Zhejiang, China (Mainland)
- Brand Name: QY
- Model Number: SHMI-701H
- Processor: TI ARM9
- Support: QT/MiniGUI graphic interface
Human Machine Interface Packaging & Delivery
Packaging Details: | one piece in a box |
---|---|
Delivery Detail: | Within 3 Working Days After The Payment Is Reached |
Human Machine Interface Specifications
HMI
1.TI ARM9 processor,456MHz
2.Built-in PRU
3.With 7''TFT-LCD,Resistive Touch Panel
4.Preassemble Linux OS
Tablet PC 7'' touch screen Human Machine Interface
1. Human Machine Interface TI ARM9 processor,456MHz,low consumption,high performance;
2. Human Machine Interface Built-in PRU,instead of Upper Computer+Lower Computer mode;
3. Human Machine Interface With 7''TFT-LCD,Resistive Touch Panel,excellent touch experience to the on-site industrial environment;
4. Human Machine Interface Preassemble Linux OS ,support QT/MiniGUI graphic interface;
5. Human Machine Interface Preassemble interfaces driver program ,provide sample program and development tool;
6. Human Machine Interface Provide customized service, customize the highest cost-effective Smart Human-Machine terminal;
7. Human Machine Interface Application Range:Inquiry Terminal,Collect Terminal,Center Control Computer,Monitor Terminal Application. HMI
Tablet PC 7'' touch screen Human Machine Interface Specifications
Application Case
Interface Configuration |
---|
7''TFT-LCD+Touch Panel |
100Mbps Ethernet Port x 1 |
Serial Ports x 3: debug x 1,RS485 interface x 1, TTL x 1 |
Wireless module interface x1 |
RTC,Hardware Watch dog,I/O so on |
Tablet PC 7'' touch screen Human Machine Interface Product Interface
QT Sample Progrm Interface
MiniGUI Sample Program Interface
Tablet PC 7'' touch screen Human Machine Interface Product Parameter
Human Machine Interface Touch Display | |
LCD | 7''TFT-LCD(16:9) |
Resolution | 800 x 480 |
Brightness | 300cd/m2 |
View | 6'O Clock |
Single-Point lifetime | Above 1,000,000 times |
Human Machine Interface System Core | |
CPU | TI ARM9 processor;456MHz |
RAM | 128M SDRAM |
Memory | 128M Nandflash(could expand to a large capacity or industrial chip ) |
Human Machine Interface Power Supply;Power Consumption | |
Power Input | DC 9~24V |
Power Consumption | ≤3W (actual measurement) |
Interface (non-standard configuration ,could be customized according to user's requirements) | |
RPU | PRU x 2,could expand to serial ports x 8 |
Serial | RS232 x 3:debug x 1 |
Serial Interface | SPI/I2C |
USB | Ports x 2:USB 2.0 OTG x 1; USB 1.1 HOST x 1 |
Network | 10/100Mbps self-adaptive full duplex port x 1 |
Audio | Linear input and output |
VGA | VGA output x 1 |
SD Card | Large capacity SD Card storage x 1 |
Other | IO,Hardware Watchdog ,back-up lithium battery,Buzzer |
Human Machine Interface Product Structure | |
Structure | Steel Structure |
Installation | Embedded Installation |
Human Machine Interface Application Environment | |
Working Temperature | -20°C~+70°C(batch user could customize -40°C~ 85°C) |
Working Humidity | 5%~ 95%, Non-Condensing |
Human Machine Interface Software | |
OS | Linux 2.6.37 |
GUI | QT4.8.2 |
Development Tool | arm-none-linux-gnueabi-gcc 4.5 |
1. Human Machine Interface Technical Support for lifetime.
2. Human Machine Interface Open Source.
3. Human Machine Interface Customisation Service.
4. Human Machine Interface Supply stably and chronically.
Wanna get a free Tablet PC 7'' touch screen Human Machine Interface hardware manual?
Wanna get an accurate price of Tablet PC 7'' touch screen Human Machine Interface?
Wanna get information of other items that are similar to Tablet PC 7'' touch screen Human Machine Interface?
Contact us NOW!
