The Case can be customized, please contact us for more informations.
New Metal Plate ARM Embedded All-In-One Machine Built- in I.MX6 Cortex-A9 Mainboard
- Adopts Freescale i.MX6 Cortex A9 series processor;
- Fanless, heat dissipation hole, low consumption, high stabilities.
- With 2D/3D/VG accelerator and 1080P h.264 video hardware codec, support dual-channel displayers with different visions;
- Integrated with rich serial ports, network port, audio, VGA,3G wireless telecommunication (Support three net segment);
- Pre-built in Linux/Android Operation System, support QT/MiniGUI graphic interface;
- Provide customization service. Obtain an exclusive embedded All-In-One Machine from Qiyang!!!
Back Side:
Front Side
System Kernel (ARM Embedded All-In-One Machine) | |
Processor |
Freescale I.MX6 Solo/Dual/Quad Core(Optional in batch order) ,1Ghz; |
DDR Memory |
1GB DDR3 SDRAM; |
Flash |
4GB EMMC; |
Power Supply, Power Consumption (ARM Embedded All-In-One Machine) | |
Power Input |
DC+12V input; |
Power Consumption |
≤3W; |
Connectors ( ARM Embedded All-In-One Machine) | |
Serial Port |
5-ch: Include 1-ch as debug port; |
USB |
2-ch USB Host;1-ch USB OTG; |
Network |
1-ch 10/100/1000M, adaptive;1-ch 3G wireless communication; |
Audio |
1-ch audio output; |
Display Connector |
1-ch VGA,1-ch HDMI, support dual-channel displayers with different visions. |
External Storage |
1-ch SD card socket; |
Connectors (ARM Embedded All-In-One Machine) | |
Materials |
Metal Plate |
Installation Method |
Embedded+ Hang |
Size |
174(Length)x50(Width)x130(Depth)mm |
Application Environment (ARM Embedded All-In-One Machine) | |
Operation Temperature |
-20℃~+70℃ ,batch order could be customized on -40℃~+85℃ industrial temp. |
Working Humidity |
5%~95%, Non-Condensing |
Software (ARM Embedded All-In-One Machine) | |
Operation System |
Linux 3.0.35 or Android 4.2.3; |
GUI |
QT,MiniGUI; |
Development Tool |
fsl-linaro-toolchain.tar.gz |
SMT Factory:
Accessory Warehouse
R&D Department
1.We provide the high performance SOM-series ARM-based module. Proven technology for underlying software and hardware, open source service, high efficient online after-sale service accelerate our customer’s development cycle.
2.OEM/ODM service will help you to achieve your ideal products. Rich experiences help us to open our customer's market quickly. ODM/OEM products right belongs to our customer.
3.Precision market positioning in industrial control area. Professional technology and attitude always let Qiyang win a great reputation in ARM embedded industry. Cooperate with Qiyang, benefit for both of us.
4.Qiyang ARM boards have already embedded in the various industrials. Touch with the end customers in different ‘’Face’’.
