High Quality Freescale I.MX6D Processor ARM Development Board/double Core Discovery Board

High Quality Freescale I.MX6D Processor ARM Development Board/double Core Discovery Board thumbnail-1
High Quality Freescale I.MX6D Processor ARM Development Board/double Core Discovery Board thumbnail-2
High Quality Freescale I.MX6D Processor ARM Development Board/double Core Discovery Board photo-1
High Quality Freescale I.MX6D Processor ARM Development Board/double Core Discovery Board photo-2
US$ 100 - 200 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
QY
Model Number:
QY
Contact Supplier Request Quote Chat Now
Zhejiang Qiyang Intelligent Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name QY
Model Number QY
Base Material FR4
Copper Thickness 1oz~4oz
Board Thickness 1.6mm
Min. Hole Size 0.15mm
Min. Line Width 0.075(3mil)
Min. Line Spacing 0.08mm
Surface Finishing HASL

High quality Freescale i.MX6D processor ARM development board/double core  discovery board







High quality Freescale i.MX6D processor ARM development board/double core discovery board



Product specifications:



ARM® Cortex™-A9,1.2GHz, compatible with solo/dual/quad core;



1MB L2 Cache,32 KB instruction and data caches, NEON SIMD Media Accelerator;



2D/3D/VG Accelerator,1080P h.264 video hardware codec,support dual 720P video encoding;



1x 20-bit parallel, MIPI-CSI2 (4-channel), three simultaneous inputs;



2-ch HOST USB HSIC, 1-ch OTG and 1-ch HOST USB integrated PHY;



1 industrial gigabit Ethernet MAC(10/100/1000MHZ);



2-ch CAN ports, each channel can up to 1 Mbps, support CAN2.0;



3 SD/MMC 4.4 and 1 SDXC;



5 SPI, 5 UART, 3 I2C, 4 PWM;



Integrated MIPI-HSI interface, 1-ch PCIe2.0 interface;



Dual LVDS interface, support resolution up to 2048*1536;



Freescale PF100 PMU;



High Assurance Boot, cryptographic cipher engines, random number generator, and tamper detection.



High quality Freescale i.MX6D processor ARM development board/double core discovery board



Product pictures:

High quality Freescale i.MX6D processor ARM development board/double core discovery board



 Hardware

Resources

CPU

Freescale i.MX6D processor,ARM® Cortex™-A9 core,1.2GHz

RAM

DDR3 SDRAM,4*256MB, total 1GB

Flash

4GB EMMC

Network

AR8035 Network Chip, adopt RGMII mode, support 10M/100M/1000M

Communication

5-ch RS232, 1 port (com0) as the debug UART, 2-ch RS232 Compatible with RS485

1-ch High speed OTG,4-ch USB, 1-ch connects to MIN_PCIE Interface

2-ch CAN, support CAN2.0, 1-ch TTL Output, 1-ch CAN output

1-ch 10/100/1000Mbps Ethernet port, with ACT/LINK indicator

Display

18-bit TFT-LCD(Compatible with 16, 24 bits), resolution up to 1920 * 1200

VGA, can be connected with universal display

2-ch LCDS Interface, each channel can support resolution up to 1920*1200

HDMI Interface, support HDMI 1.4



Audio

McASP audio interface; binaural output; MIC audio input

Input Interface

4-wire resistive touch panel

Standard I2C Capacitive panel

CAMERA Interface, standard interface support OV5642 camera module

Expansion Interface

MINI_PCIE 2.0

SIM Card

Memory Interface

1-ch SD Card interface

1-ch SATA Hard disk interface, SATAII standard, speed up to 3.0Gbps

Other

Reset circuit, Watch dog, RTC, Buzzer, JTAG interface

Power Input

+12V power supply, can support +4.75V~+18V wide range voltage supply

Resource

Development Tools

Development environment: Virtual Machine VM9.0.2+ubuntu12.04.1

Application layer development debug tool

Cross-compiler

Common terminal development debugging tool

Image File

OS image file, support multiple resolution display

Test Program

Interface using demo test program and test program source code

Source Code

Bootloader, kernel, system source code

Manual

Mainboard User manual,Device Manual

Schematic

Mainboard structure size chart

Electrical Specification

Size

160mm*105mm

PCB

8-layer high precision immersion gold process

Power

Consumption

≤3W

Operation Temperature

-20°C ~ +70°C

Operation Humidity

5% ~ 95%, Non-Condensing





High quality Freescale i.MX6D processor ARM development board/double core  discovery board :

• Textile Industry, Numeric Control Industry, Automobile Electronics, Industrial Touch Screen Control System, Robot Vision, Media Deal Wireless Application, Digital Applicance, On-board Equipment, Communication Equipment, Network Terminal, etc.









Company Information






Packaging & Shipping

  High quality Freescale i.MX6D processor ARM development board/double core discovery board


Our Services

Technique support is our special service for our customer after sales. We also have OEM and ODM service for special requirements.
