BAOMA HIGH EFFICIENT EDM ENGRAVING AND MILLING Mini Machining Center BMDX120100
US$ 1,000 - 80,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Vertical
Place of Origin:
Jiangsu, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
BAOMA High Speed Cheap Cnc Milling Machine BMDX8060 Quality ChoiceUS$ 1 - 555,555MOQ: 1 Set -
BAOMA High Accuracy Mini Cnc Horizontal Machine Center BMDX6050US$ 1,000 - 80,000MOQ: 1 Set
-
Low Price CNC Milling&engraving MachineUS$ 1 - 555,555MOQ: 1 Set
-
Baoma High Speed Cheap Cnc Milling Machine Price/engraving Machine Bmdx8060US$ 0.01 - 77,777MOQ: 1 Set
-
Baoma High Speed Cheap Cnc Milling Machine Price/china Cnc Milling Machine Bmdx6050CUS$ 0.0001 - 77,777MOQ: 1 Set
Condition
New
Type
Vertical
Place of Origin
Jiangsu, China
Brand Name
BAOMA
Model Number
BMDX120100
Voltage
CUSTOMIZED
Power(W)
18KVA
Dimension(L*W*H)
2700*3045*3050mm
Weight
7500KGS
Certification
ISO9001 ISO 14001
Warranty
12 months
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
mini machining centera)Control System : Spain FAGOR / Taiwan SYNTEC
b)Spindle Speed: 18000 rpm
c)Rapid Speed: 10000 mm/Min
HIGH EFFICIENT EDM ENGRAVING AND MILLING mini machining center BMDX120100
a)Product Description
CNC Engraving & Milling Machine BMDX120100 Parameters
| Travel/space | X/Y/Z axis travel | mm | 1000/1200/550 |
| Table upper surface to spindle nose end face | mm | 140-690 | |
| Accuracy | Positioning | mm | ±0.005/300 |
| Repeatability | mm | ±0.003/300 | |
| Table | Table dimension | mm | 1050x1300 |
| Max. load on table | Kg | 800 | |
| Power(X Y Z) | Kw | 1.8,1.8,1.8 | |
| T shape groove | mm | 18TxP150x7 | |
| Spindle | 18000rpm / 7.5kw / BT30 | ||
| Feeding speed | Rapid speed(X/Y/Z) | mm/min | 15000 |
| Cutting speed(X/Y/Z) | mm/min | 6000 | |
| Outer size and weight | Machine height | mm | 3050 |
| Floor space | mm | 2700x3045 | |
| Net weight | Kg | 7500 | |
| Total input power | Kw | 22 | |
- The opening protector design makes big work piece loading easily.
- In design we use the advanced finite element software to do dynamic simulation and construction analysis in order to ensure the machine possesses the best construction rigidity, machining precision and machining steady.
- X, Y, Z use precision ball bearing screw, all have be hauled advance, that will ensure machine to get the best precision and make the position error to the lowest.
- The slop bed and the big capacity water tank make scrap to be cleaned easily.
- The one key to make sure the machining result excellent is high speed and precision spindle. The power source for small tool engraving comes from the electric motor of high speed and precision spindle. If you want to make the small tool working in good condition, the spindle electric motor has the follow characteristics: high speed rolling, small rolling shake, and small rolling noise.
- Excellent design make the machine so good operation.
- Using the advanced cooling-water machine to cool down the spindle, make sure the spindle keeping long life and machining having high precision.
Our company offer Taiwan SYNTEC, LNC and Germany PA system for the customer’s request, and try our best to offer you the best products.
- Taiwan Syntec940i specialist control system
- Be able to connect the man-machine communicated interface of Easy view and Digital
- Wide range to connect with other equipment
- Convenient to communicate through the figural interface
- Convenient to renew the software through the mobile hard disk
- Control several axes in different synchronous way by PLC
- The function of video mending
- Nice panel design and steady controller design
PACKING:
Standard Packing List
| No | Item | Specification | Quantity | Remark | |||||
|---|---|---|---|---|---|---|---|---|---|
| 01 | Main machine | 1 | Include Electrical box | ||||||
| 02 | Cooler tank | 1 | |||||||
| 03 | Foundation | 6 | |||||||
| (1) | Screw | M20*1.5 | 6 | ||||||
| (2) | Foundation nut | 6 | On machine | ||||||
| (3) | Nut | 6 | |||||||
| (4) | gasket | 20 | 6 | ||||||
| 04 | Document box | ||||||||
| (1) | Manual | 1 | |||||||
| (2) | Quality document | 1 | |||||||
| (3) | Controller system manual | 1 | |||||||
| (4) | Handle wheel | 1 | |||||||
| (5) | Three color alarming lamp | 1 | On machine | ||||||
| (6) | Working lamp | 1 | On machine | ||||||
| 05 | Accessories | ||||||||
| (1) | ER25 tools holder | 1 | |||||||
| (2) | Compose pressure board | M12 | 1 | ||||||
| (3) | Transfer line | 1 | |||||||
| (4) | Cutting working fluid | Rate 1:20 | 10 litre | ||||||
| (5) | Spindle working fluid | Rate 1:20 | 10 litre |
||||||
Standard accessories:
1. Auto lubrication system
2. Full closed sheet metal cover
3. Three color alarming lamp
4. Foundation block
5. Operation and maintenance manual
6. Composite fixing plate
7. flat clamp
8. ER25 clamp 4-12
Optional spare parts
| No. | Item | ||
|---|---|---|---|
| 1 | Oil chiller for spindle. | ||
| 2 | Tool presetter. | ||
| 3 | Assistant working table. | ||
| 4 | 4th Axis | ||
| 5 | Magazine |
