50kw Wind Grid Tie Inverter

50kw Wind Grid Tie Inverter thumbnail-1
50kw Wind Grid Tie Inverter photo-1
US$ 1,000 - 100,000 MOQ: 10 Sets
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
BOS
Model Number:
BNWG
Contact Supplier Request Quote Chat Now
Shandong BOS Energy Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name BOS
Model Number BNWG
Type Plant
Electricity Generator Type Wind Power
Output Voltage (V) 400

Specifications

50kw wind grid tie inverter
1. 5kw ~500kw
2..CE approved

50kw wind grid tie inverter

product advantages:

1. using IPM from Mitsubishi company as the power components.

2. using American ATEMEL company microprocessor as figure controller.

3. perfect protection and warning functions.

4. MPPT (Maximum Power Point Tracking )technology.

5. circuit frame compact,Max. Efficiency≥94%

6. Outdoor stainless steel casing, entire sealed  installation

7. input voltage range wide,MAX. can be 1150VDC

8. communication,multi communication interface can be selected

9. pure sine wave output,automatically synchronized with the grid tracking,power factor close to 1, Current low harmonic content, non-polluting power grid, no impact

10. Inverter current closed-loop control, power controllable

11. big-screen English  LCD, perfect display, interface-friendly.



parameters:



Wind turbine grid-on system specialized single-phase inverter



type

BNWG-1KD

BNWG-3KD

BNWG-5KD

rated capacity

1KW

3 KW

5 KW

Rated AC output power

1KW

3KW

5KW

Max. AC output power

1.2KW

3.6KW

6KW

insulate mode

Low frequency transformer

Recommended wind turbine  power

1KW

2KW

3-4KW

Max. open circuit voltage

450V



780V

MPPT range

150~450VDC

180~450VDC

180~780VDC

Max. input current

6.7A

15A

25A

connecting mode of battery board

water-proof direct-plug terminals

Max. efficiency

94%

Europe efficiency

92%

operating range utility voltage(single phase)

180~265WC

operating range utility frequency

50HZ±2%&60HZ±2%

Total Harmonic Distortion(THD)

<3%

power factor

≥0.99

communication Interfaces

RS485/RS232

Electrical insulation properties

1500Wc,1minute

operation surroundings Temperature

-25~+60°C

opreation surroundings Humidity

0~100%

Protection

Protection for input connecting contrary, input lack of voltage, output over load, output short circuit and over heat.

cooling mode

Windy

noisy

<40dB

waterproof and Dustproof Class

IP20(indoor),IP65(outdoor)

dimension(L×W×Hmm)

300*150*500

350*200*500

430*280*630

Weight(kg)

15

45

60



















Wind turbine grid-on system specialized three-phase inverter



model

BNWG-10KS

BNWG-30KS

BNWG-50KS

BNWG-100KS

BNWG-250KS

BNWG-500KS

rated AC output power

10 KW

30 KW

50 KW

100 KW

250 KW

500 KW

insulate mode

Low frequency transformer

Max. open circuit voltage

780V



1150V



MPPT range

200~780V

400~780V

400~1150V

Max. input current

50A

150A

125A

250A

625A

1250A

Can access array of parallel group

10group

connecting mode of battery board

connection terminals

Max. efficiency

95%

Europe efficiency

94%

operating range utility voltage(three phase)

320~440AC

operating range utility frequency

50HZ±2%

Total Harmonic Distortion(THD)

<3%(rated power)

power factor

>0.99

Zero power consumpt at night

<10W

communication Interfaces

RS485

Electrical insulation properties



1500Wc,1 minute

operation surroundings Temperature

-25~+60°C

opreation surroundings Humidity

0~100%

Protection

Protection for input connecting contrary, input lack of voltage, output over load, output short circuit and over heat.

cooling mode

windy

noisy

<50dB

waterproof and Dustproof Class

IP20(indoor),IP65(outdoor)

Size(L×W×Hmm)

550*480*980

800*600*1800

800*600*2260

2250*850*2180

2400*800*2260

Weight(KG)

150

400

600

800

1200

1800





 50kw wind grid tie inverter50kw wind grid tie inverter
