Frequency Converter 800KVA

Frequency Converter 800KVA thumbnail-1
Frequency Converter 800KVA photo-1
US$ 50,000 - 64,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
BOS
Model Number:
AC60-333800
Contact Supplier Request Quote Chat Now
Shandong BOS Energy Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name BOS
Model Number AC60-333800
Input Voltage AC130-280V
Output Voltage AC220-380V±1%
Output Power 800KVA
Output Frequency 50-60Hz±0.01%
Output Current 220A

Frequency Converter 800KVA

Technical parameters:

Model

AC50-333800

Capacity

800KVA

Output current

1600A

Circuit model

IGBT/PWM pulse width adjustment mode

 AC  input

voltage

450-780V

Frequency

30-70Hz

AC output

Phase

Single phase

Voltage

220V±1%

Output frequency

50Hz or 60Hz

frequency stability

≤±0.01%

voltage stability

≤1%

Wave distortion

≤2%

Reaction time

dynamic response quick, when load 0-100% change, the steady-state response time <20ms

Display/resolution

Digital frequency meter

Resolution 0.1Hz

Digital voltage meter

Resolution 0.1V

Digital current meter

Resolution 0.1A

Digital power/PF meter

Resolution 0.1W

Work efficiency

efficiency more than 90%, be suit for wide-load, can be for the inductive, capacitive, resistive, and any mixed loads

Protective device

 the importation of non-fuse switch, without output fuse switch, the electronic circuit to detect over-voltage express .Over voltage, over current, over temperature, over load, short circuit, and automatic alarm

Insulation reactance

Above 500Vdc 20MΩ

Pressure endurance insulation

1800Vac/5Ma/1minute

Cooling device

Compulsive fan cooling

Others

isolation transformer output, safe reliable, good anti-jamming

environment

Working temperature

-10°C-50°C

Relative humidity

0-90%(Non-condensing)

Altitude

1500meters

Dimension mm (W×L×H)

3000×800×2060



Features:
1.Input voltage: 450~780V
2.Input frequency: 30~70Hz
3.Output voltage: 480V/780V±0.5%
4.Output frequency:50Hz±0.01%
5.Wave distortion: <1%
6.Isolation transformer output, safe and credible
7.Auto-protection and alarm for output overvoltage, over current, overheat, short circuit
8.Efficiency reach above 90% ,widely applicable load,for nasty, capacitive resistance,any combination of the load
