Specifications
20KW frequency converter single phase1.Reliability
2.Interface-friendly
3.High Stability
20KW frequency converter single phase
1.Have a high voltage, over current and short-circuit and overheat warning device
2.16 bit microprocessors, the intelligent control and easy operation
3.Low distortion interference,input and output are completely isolated , safe and reliable
4.Unique transient waveforms value control and low distortion, high precision control
5.Dynamic quick,when load changgees in 0 - 100% ,stationary response time <0.1S
6.Provide world standard grid voltage,frequency,simulation testing all kinds of
electrical products
7.With no radiation,small harmonic ingredients and special treatment,no distracting
8.The efficient up to above 85% wide applicable load,can be perceptual capacitive resistive load
9.Import original german siemens IGBT high frequency inverter and deck mechanism
10. Output voltage:low-grade:0-150 V,high grade: 0-300V adjustable continuously
11.A machine has more function,surface and source are one:with the nearest 0.5 level
output voltage, current and frequency and power the power factor watch.
Model | 31150 | 31200 | 313000 | |
Capacity | 15KVA | 20KVA | 30KVA | |
Outputlimit currency | L:126A | L:168A | L:250A | |
| H:63A | H:84A | H:125A | |
Circuit model | IGBT/SPWM pulse width adjustment mode | |||
Output frequency | 50Hz/60Hz 45-65Hz | |||
Load stability | ≤±1% | |||
frequency stability | fixed-frequency≤±0.01%,frequency modulation≤±0.1% | |||
Input voltage | 380V±10% | |||
Phase | three phase four wire | |||
Wave distortion | ≤3% | |||
Output voltage | low-grade:0-150V continuous-tuning; high-grade:0 - 300 V continuous-tuning | |||
Reaction time | ≤2mS | |||
DPI ( dots per inch ) | frequency meter | 0.1Hz | ||
| Voltage meter | 0.1V | ||
| Current meter | 0. 1A | ||
| Power meter | 0.1W | ||
Ammeter display | Frequency, voltage, current, power or PF 4 number display | |||
Protection function | over voltage, over current, over temperature, over load, short circuit, and automatic alarm | |||
Insulation reactance | 500Vdc 20MΩ | |||
Pressure endurance insulation | 1500Vac/5mA/1min | |||
Cooling model | Compulsive fan cooling | |||
Working temperature | -10°C-45°C | |||
Relative humidity | 0-90%(No condensing) | |||
Altitude | 1500meters | |||
Dimension (W×L×H) | 830×450×1100mm | |||
Best of system (B.O.S) is the global company that specializes in designing and manufacturing the power supply, which products of high reliability result from the most advanced technique of the aerospace and the military. We always take the technology of inverter as the core for many years,the products include Conversion Power Supply (widely used electric power, communication, Locomotive), Frequency Conversion Power Supply, Aviation Military Special-purpose Power Supply (400Hz frequency conversion, 28.5 Direct-current power), Uninterruptible Power Supply (UPS), Emergency Power Supply (EPS) and new energy generation green power supply (solar energy and wind power system) etc.
