YZ-S3 3 CAVITY Semi Automatic Used Pet Bottle Blow Molding Machine

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Other, bottle blowing machine

Model Number:

Wenzhou Changs International

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, bottle blowing machine

Model Number YZ

Place of Origin Zhejiang, China

Plastic Type Other

Automatic Yes

Specifications

used pet bottle blow molding machine
3 CAVITY SEMI AUTOMATIC BLOW MOLDING MACHINE BOTTLE VOLUME 50ML TO 2L.

used pet bottle blow molding machine

3 CAVITY SEMI AUTOMATIC BLOW MOLDING MACHINE BOTTLE VOLUME 50ML TO 2L.

Our machine use Three phase : 220V/60HZ

Single phase: 220V/60HZ

We will make the electricity strictly according your requirements.

Mould steel material: 45#.

TYPE	ITEM	UNIT	TECHNICAL DATA HY-B3
CONTAINER	Product material		PET
	Container volume	L	≤1.5
	Theoretical Output	Pcs/hr	1200
	Max. bottle height	mm	320
	Max.bottle diameter	mm	90
MOULDING	Max.moula plate dimension(LxW)	mm	480
	Max.mould thickness of mould	mm	220
	Clamping force	KN	130
	Mould opening stroke	Mm	370
AIR COMPRESSOR	Working pressure	Mpa	0.8-1.0
AIR COMPRESSOR	Air compressor for blowing	Mpa	2.0
MAIN MACHINE ELECRICITY	Power	KW	12
MAIN MACHINE ELECRICITY	Voltage/Frequency	V/HZ	380-240-110/50-60
MACHINE SIZE AND WEIGHT	Main machine(LxWxH)	M	1700×780×2050
	Main machine weight	KG	800
	Heater(LxWxH)	M	2080×630×1380
	Heater weight	KG	330
SAFETY	SAFETY INTER-LOCKING DEVICE		Auto-emergency alarm
