Home > Manufacturing & Processing Machinery > Plastic Machinery > Injection Molding Machine > YZ-6 Full-automatic Water Bottle Blower

YZ-6 Full-automatic Water Bottle Blower

Wenzhou Changs International

YZ-6 Full-automatic Water Bottle Blower photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Other, bottle blowing machine

Model Number:

YZ-6

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Other, bottle blowing machine

Model Number YZ-6

Place of Origin Zhejiang, China

Plastic Type Other

Automatic Yes

Specifications

automatic water bottle blower
Stable performance with advanced PLC
Conveying preforms automatically with conveyor

automatic water bottle blower

YZ-6 FULLY AUTOMATIC BOTTLE BLOWING MACHINE.

Features:

Stable performance with advanced PLC
Conveying preforms automatically with conveyor
Strong clamping force with high

Procedure:

Step 1. Put the preform into preform container and the conveyer will take the preform to orientation units automatically.

Step 2. Load the preform at neck up to preform holder, and then preform is conveyed into baking tunnel.

Step 3. After heating, preform is conveyed into the blow station, then close the mold, stretch and blow under low pressure and high pressure, exhaust, open the mold.

Step 4. The finished bottle is taken off by automatic discharging system

Paramters,

ITEMS	UNIT	YZ6
No. OF MOULD	SET	6
WORKING PRESSURE	Bar	7-8
AIR BLOWING PRESSURE	Bar	30
HEIGHT OF BOTTLE	mm	330
STROKE OF MOULD OPENING	mm	130
THICKNESS OF MOULD	mm	190
HEAT UNIT GROUP	Group	4
HEATED-LIGHT LAYER	Layer	9
MAX. HEAT POWER	kw	35
VOLTAGE	V	220-380
FREQUENCY	Hz	50/60
PREFORM LENGTH	mm	≤180
BITTLE NECK DIAMETER	mm	20-28
BOTTLE DIAMETER RANGE	mm	20-115
PREFORM RAW MATERIAL	kg	PET
VOLUME RANGE	Layer	0.2-2.25
CAPACITY FOR MINERAL BOTTLE	Pcs/h	7500
WEIGHT	kg	≤5800
DIMENSION OF MAIN MACHINE	cm	310231198
DIMENSION OF HEATER	mm	It is the section of the main machine and contained it.
PREFORM-TIDIED MACHINE SIZE	mm
DIMENSION OF ELECTRICAL BOX	mm
