Technical Parameter
Model | SJ-4/YT-2600 | SJ-55/YT-2800 | SJ-60/YT21000 |
Applied Materials | LDPE / HDPE / LLDPE | ||
Screw Diameter | 45mm | 55mm | 60mm |
Screw Ratio L/D | 28:1 | 28:1 | 28:1 |
Blow Film Motor Power | 11kw | 15kw | 18.5kw |
Max.Extrude Output | 36kg/h | 50kg/h | 70kg/h |
Film Head Dia | 6080 | 80130 | 80160 |
Blow Film Width | 600mm | 800mm | 1000mm |
Blow Film Thickness | 0.008-0.10mm | 0.008-0.10mm | 0.008-0.10mm |
Length Range of Printing | 191-1200mm | 191-1200mm | 191-1200mm |
Printing Width | 560mm | 760mm | 960mm |
Total Power | 28kw | 32kw | 40kw |
Weight of machine | 3800kg | 4200kg | 5000kg |
Overall Dimensions | 6000×2400×4000mm | 6200×2600×4300mm | 6400×2800×4800mm |
Use:
It is applied to blowing plastic films like low density polytene(LDPE), high density polytene
(HDPE) and linear low density polytene(LLDPE), etc. It is widely applied to packing foodstuff, clothing, rubbish bags, vest ones, etc. In the civil and industries sectors.
Characteristics:
The unit integrated film-bolwing & printing designed by us can save labor force, workshop rooms, and improve the quality of products and economic results.
OPTIONAL EQUIPMENT:
1. AUTO LOADER
2. CORONA
3. DIE ROTARY DEVICE
4. AIR COMPRESSOR
5. GRAVITY METRIC DEVICE
Sample:
1. Warranty
1 year limited warranty after installation.If the spare parts is broken in the warranty
period , we will send a free replacement parts to you .
2. Installation and Training
We can send 1-2 engineers to buyers factory to install and set up the machines and
training, but all the charges for the engineers should be paid by buyer.
3. Quotation
The quotation is available in 60 days
We have a professional transport channel
1.About us
Wenzhou Changs Machinery Co.,Ltd is one of the first company specialized in manufacturing printing machines, packing machines, plastic machine and paper converting machines,has owned export and import license since 2004.
To consider our full service convenience, we have set up service office and showing room at DRAGON-MART of Dubai to provide technical service for customers from Middle East and Africa in 2006, and also we have established technical support offices in Mexco, Egpty and Singapore, our service has satisfied with all of our customers. We enjoy sound reputation in oversea’s market and domestic.
2.Certificate
3. Cooperative partner
