Specifications
barrel-type plastic vest bagsfrequency speed and high quality
COMPUTER AUTOMATIC HEAT-SEALING AND HEAT-CUTTING BAG-MAKING MACHINE
Characteristics:
This machine is suitable for making barrel-type plastic vest bags of natural colour and colour-printed bound plastic vest bags.It adopts advanced photoelectric eyes tracking which makes the printing pattern position accurate without error,the sealing synchronize with the heat-cutting without any pulling force and sealedbottom be firm and beautiful.Equipped with variable frequency speed regulating motor,it has many automatic protection functions such as energy-saving, over-load,over-voltage and over-current etc.And equipped with automatic counting device, it can arbitrarily set the binding quantity and can automatically discharge and reset after the bags are piled to the set quantity.
Main Technical Parameter:
Model |
SDFR-500 |
SDFR-700 |
Max.Sealing & Cutting Width |
500mm |
700mm |
Sealing & Cutting length |
100-1000mm |
100-1000mm |
Sealing & Cutting Thickness |
0.005-0.5mm |
0.005-0.5mm |
Error in Length |
±1mm |
±1mm |
Bag-making Speed |
40-120pcs/min |
40-120pcs/min |
Power of Main Motor |
0.75kw |
1.1kw |
Heating Power |
2kw |
2.4kw |
Total Power |
3kw |
3.8kw |
Weight of Machine |
800kg |
900kg |
Overall Dimension(L×W×H) |
2600×1100×1500mm |
2600×1300×1500mm |
