200ml,330ml,500ml 1L and 2Lwater Bottle Automatic Blowing

200ml,330ml,500ml 1L and 2Lwater Bottle Automatic Blowing thumbnail-1
200ml,330ml,500ml 1L and 2Lwater Bottle Automatic Blowing photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Bottle
Plastic Processed:
PET
Contact Supplier Request Quote Chat Now
Zhangjiagang City B
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Bottle
Plastic Processed PET
Blow Moulding Type Stretch Blow Moulding
Automatic Yes
Place of Origin Jiangsu, China
Brand Name sanofi
Model Number HY-B-I
Voltage 220V OR 380V
Power(W) 14
Dimension(L*W*H) 400*600*1500MM
Weight 900KG
Certification ISO, CE
Warranty 14months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.200ml,330ml,500ml 1L and 2Lwater bottle automatic blowing
2.price is low but the quality is good

200ml,330ml,500ml  1L and 2Lwater bottle automatic blowing





Features:

 Full automatic blow molding machine is suitable for producing PET plastic containers and bottles in all shapes. It is widely used for producing the carbonated bottle, mineral water bottle, pesticide bottle, oil bottle, cosmetics bottle, wide-mouth bottle and hot filling bottle etc.

*Reasonable design, full automaticlly control, save power and labor.
*Feeding system carries the preforms by robot arms automatically.
*Infrared oven heater adopts the quartz lamp to heat the PET tube.
*Fully automatic process with low investment, high efficiency,quick and safe for operation, easy for maintenance.
*We have perfect service after sales .
*Adopting high quality components.

Main Parameter:



ModelITEMCM-A2CM-A4
ProductivityDepend on bottle design1800-2000PCS/H3200-4000PCS/H
Product typeVolume0.1-2L0.1-2L
Body diameterless 100mmless 100mm
Heightless 310mmless 310mm
Neck diameter38mm38mm
MouldCavity24
Mold thickness240mm240mm
Mold size260*240*370mm510*240*360mm
Main machine powerElectrical source power380V/220V 50/60HZ 3Phase380V/220V 50/60HZ 3Phase
Power25kw49kw
Really use power6.5kw13kw
Air systemHP air compressor1.4 m3/min 3.0Mpa2.0 m3/min 3.0Mpa
LP air compressor1.0 m3/min 1.0Mpa1.6 m3/min 1.0Mpa
Air Tank0.6m3 3.0Mpa0.6m3 3.0Mpa
Air dryer1.0m3/min 3.0Mpa2.0m3/min 3.0Mpa
Cooling waterWater Chiller3HP3HP
MachineSize(L*W*H)1900*1280*1930mm1900*1860*1930mm
Weight2000kg3600kg
Preform unscramblerSize(L*W*H)2000*950*2480mm2000*950*2480mm
Weight250kg250kg











200ml,330ml,500ml 1L and 2Lwater bottle automatic blowing200ml,330ml,500ml 1L and 2Lwater bottle automatic blowing

200ml,330ml,500ml 1L and 2Lwater bottle automatic blowing200ml,330ml,500ml 1L and 2Lwater bottle automatic blowing
