Paper Cup Printing and Punching Machine

Paper Cup Printing and Punching Machine photo-1
Paper Cup Printing and Punching Machine photo-2
US$ 30,000 - 35,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Die-cutting Machine
Computerized:
Yes
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO / SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Die-cutting Machine
Computerized Yes
Place of Origin Zhejiang, China
Brand Name changs
Model Number JMQ930
Voltage 380V50HZ
Power(W) 11KW
Dimension(L*W*H) 4840mmx2180mmx1880mm
Weight 5500kg
Certification SGS
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

Automatic paper cup die cutting machine

Paper cup printing and punching machine





Description

 JMQ 930 high Speed Automatic Reel Die-cutting Machine is the professional equipment which uses for cutting various kind of popular paper and PE coated paper,be applicable to printing,packaging,paper cup and other to the die-cutting area,cutting lengh can be setted in touch-screen, it is convension and precise . And it can die-cut the blank paper and printed paper .Clutch is pneumatic clutch ,be fast and reliable.



Technical Parameter:

Model

JMQ-930

Die cut speed

60~110 Times/Min

Max pressure

1200KN

Length of cutting

<25m

Diameter of roll paper

<1.5m

Paper thickness

180-350gsm

Paper Width

360-900mm

Max die cut size

580x900mm

Paper feeding speed

>35m/min

Air compressor

1.0m3/min,(0.8MPa)

Length of roller

1000mm

Main motor Power

7.5KW

Total power

11KW

Dimension(LxWxH)

4840mmx2180mmx1880mm

Weight

5500Kg



 Sample

Paper cup printing and punching machine



Our Services

1. Warranty

              1 year limited warranty after installation.If the spare parts is broken in the warranty

              period , we will send a free replacement parts to you .

2. Installation and Training

              We can send 1-2 engineers to buyers factory to install and set up the machines and

              training, but all the charges for the engineers should be paid by buyer.

3. Quotation

             The quotation is available in 60 days

Packaging & Shipping

We have a professional  transport channel

Paper cup printing and punching machine

Company Information

1.About us

      Wenzhou Changs Machinery Co.,Ltd is one of the first company specialized in manufacturing printing machines, packing machines, plastic machine and paper converting machines,has owned export and import license since 2004.

       To consider our full service convenience, we have set up service office and showing room at DRAGON-MART of Dubai to provide technical service for customers from Middle East and Africa in 2006, and also we have established technical support offices in Mexco, Egpty and Singapore, our service has satisfied with all of our customers. We enjoy sound reputation in oversea’s market and domestic.

2.Certificate

Paper cup printing and punching machine

3. Cooperative partner

Paper cup printing and punching machine
