pvc laboratory mixer
Model Data |
Capacity (L) |
Effective Capacity |
Motor kW |
Main shaft Speed rpm |
Heating Method |
Discharge Method |
SHR-10A |
10 |
7 |
2.2 |
2000 |
Electricy |
Hand work |
SHR-50A |
50 |
35 |
7/11 |
750/1500 |
Pneumatics |
|
SHR-100A |
100 |
75 |
14/22 |
650/1300 |
||
SHR-200A |
200 |
150 |
30/42 |
475/950 |
||
SHR-300A |
300 |
225 |
40/55 |
475/950 |
||
SHR-500A |
500 |
375 |
47/67 |
430/860 |
||
SHR-800A |
800 |
600 |
60/90 |
370/740 |
||
SHR-200C |
200 |
150 |
30/42 |
650/1300 |
self-friction |
Pneumatics |
SHR-300C |
300 |
225 |
47/67 |
475/950 |
||
SHR-500C |
500 |
375 |
83/110 |
500/1000
|
Mixer unit(hot and cold mixer)
Application & Features:
SRL-Z series mixer unit is applicable for mixing, colouring and drying of various resin such as poly, PE,PP,PVC polypropylene, poly chloride etc.
SRL-Z series mixer unit combines hot mixer and cooler mixer together .The materials after hot mixer can be getting into cooler mixer for cooling automatically ,exhausts remaining gases and avoids agglomeration. Through setting the time or temperature, the machine can be operated automatically.
SRL-Z series mixer unit is developed by importing and absorbing foreign advanced technology. By adopting PLC control, it features high automatic level, good mixing effect, complete function, compact structure and beautiful appearance. It is the ideal equipment for plastic mixing.
Main technical parameter:
| Model | SRL-Z100/200 | SRL-Z200/500 | SRL-Z300/600 | SRL-Z500/1000 | SRL-Z800/1600 |
| Total capacity(L) | 100/200 | 200/500 | 300/600 | 500/1000 | 800/1600 |
| Effective capacity(L) | 75/160 | 150/320 | 225/390 | 375/650 | 600/1050 |
| Mixer Speed(rpm) | 650/1300/180 | 475/950/130 | 475/950/130 | 430/860/60 | 370/740/50 |
| Mixed time(min) | 6~10 | 6~10 | 6~10 | 6~10 | 6~10 |
| Power(kw) | 14/22/7.5 | 30/42/11 | 40/50/11 | 55/75/18.5 | 60/90/22 |
| Measurement(mm) | 3780x1870x2250 | 4580x2240x2470 | 4580x2440x2570 | 4600x3000x4050 | 4850x3860x6650 |
| Weight(kg) | 3200 | 3400 | 4200 | 5800 | 8700 |
IF YOU NEED MORE INFORMATION,PLEASE CONTACT TO ME.TEL:0086-512-58668982
