Specifications
Electric heating cableApplication for floor heating,snow melting,freezed protection
Eco-friendly,durable
Vegetable Greenhouse Electric Heating Cable Wire
Description
Minco intelligent electric heating system is highly efficient, energy-saving, concealed low-temperature radiant warmming system. It is charcterized by green and environment-friendliness.It's energy conservation, low cost of installation and maintenance. The application of the products is extensive:underfloor ,roof,pipe,driveway,bathroom.We are the best in China.Don't hesitate,Minco will provide you a warm life.
Deatils
Brand Name |
Minco |
Heating Cable Type |
Low voltage twin conductor heating cable |
Model |
TXLP/2R/18.5 |
Power |
18.5W/M |
Voltage |
220V (can be customized) |
Color |
Blue |
Warranty |
10 years |
Life span |
50 years |
Certification |
CE, GOST, ROHS, FIRE RESISTANT |
Range for Application |
Floor heating, snow and ice melting, pipe insulation, baby animal husbandry and soil heating, etc, any place that need to heat.
|
Structure
|
1.Corewire: alloy wire |
Series structure without voltage drop; the temperature of whole cable is even. |
|
2.Insulation: cross linked polyethylene |
The long-term working temperature is 105°C The instantaneous overload temperature is 205°C |
|
3.Ground wire: Tin plated copper |
8 tin plated copper wires with a diameter of 0.4mm |
|
4.Shieldinglayer: luminum foil |
Thickened Aluminum composite membrane shielding layer can shield the electromagnetic radiation effectively which already passed the American electromagnetic radiation detection and the European U nion CE certification. |
|
5. Jacket: PVC |
Antiseptic,waterproof and anti-aging |
| Note | Heating wire and copper wire are welded together before extruded insulation,our production process can prevent leakage and gurantee the continuiry of metal shielding. |
Specification
TXLP/2R series twin conductor Electric Heating Cable(220V 18.5W/M) | |||||
Power(W) |
Cable model | Voltage(V) | Standard length(M) | Power per meter(W/M) | Total value of resistance(Ω) |
| 3150 | TXLP/2R/18.5 | 220 | 170.3 | 18.5 | 15.4 |
| 2800 | TXLP/2R/18.5 | 220 | 151.4 | 18.5 | 17.3 |
| 2600 | TXLP/2R/18.5 | 220 | 140.5 | 18.5 | 18.6 |
| 2400 | TXLP/2R/18.5 | 220 | 129.7 | 18.5 | 20.2 |
| 2200 | TXLP/2R/18.5 | 220 | 118.9 | 18.5 | 22.0 |
| 2000 | TXLP/2R/18.5 | 220 | 108.1 | 18.5 | 24.2 |
| 1800 | TXLP/2R/18.5 | 220 | 97 | 18.5 | 26.9 |
| 1600 | TXLP/2R/18.5 | 220 | 86 | 18.5 | 30.2 |
| 1370 | TXLP/2R/18.5 | 220 | 74.1 | 18.5 | 35.3 |
| 1250 | TXLP/2R/18.5 | 220 | 67.6 | 18.5 | 38.7 |
| 1000 | TXLP/2R/18.5 | 220 | 54.1 | 18.5 | 48.4 |
| 840 | TXLP/2R/18.5 | 220 | 45.4 | 18.5 | 57.6 |
| 700 | TXLP/2R/18.5 | 220 | 37.8 | 18.5 | 69.1 |
| 600 | TXLP/2R/18.5 | 220 | 32.4 | 18.5 | 80.7 |
| 500 | TXLP/2R/18.5 | 220 | 27.0 | 18.5 | 96.8 |
| 400 | TXLP/2R/18.5 | 220 | 21.6 | 18.5 | 121.0 |
| 300 | TXLP/2R/18.5 | 220 | 16.2 | 18.5 |
161.3 |
Application
Advantges
Safe: High efficient and convenient heating system.
Automatism: Heating system can automatically (by thermostat)measure the heating requirement, and timely adjust the heating temperature.
Economical: The cost of installation and operation is relatively low; our heating system can efficiently avoid damage and save maintain fees.
Environmental: Our heating system use the cleanest power which are popular between customers.
Spanlife:Almost 50m years
Certifiction:CE,ROHS GOST,FIRE RESISTANT
Warranty:10 years
Installation
Tips
1). Heating cable fix materials: Aluminum tape.
2). Cross tube materials: Use steel or PVC tube.
3). Don't damage cable. The bend radius should be more than 6 times of thickness of
cable.
4). Heat insulation materials should be dry and the joint of cable should be sealed.
5). The junction box should be sealed.
6). Protective sleeve must not be damaged during installation, and the core wire
can not bare.
7). The heating cable should be installed accurately according to the design graphics.
Manufacturing and Factory
Delivery deatails
We will prepare shipping asap once we receive your money, nd give you the tracking number after we send out your goods. Usually within 5-35 working days you can receive your item. Please wait patiently!
