Countersunk Finishing Washers Fasteners Cold Header
cold forging machine: working factory
Our factory produces Multistage bearing cold former. From type 11Bfive stages to 33Bsix dies with 20types machine.We also could make special machine according the customers requirement.
The main body adopt qt500 cast metal. Great tensile strength, high resistance to wear.
The main slide block adopt V types design and alloy steel. Strict heat treatment. It could guarantee the high precision and stability under high speed working.
The driving gear of tongs adopt planetary gear. It could strict control tongs overturn/translation and make the feeding correctly.
The machine have air brake system/automatic malfunction detection system/safety protect device. It will be automatic stop when it has malfunction. Easy operation, High Safe.
cold forging machine: on testing
Specification
17B-6SL Multistage Cold Former
Dies:6
Stage Gap: 72mm
Main Slide Block Trip: 140mm
Max Shear Length:35mm
Max Shear Diameter:18mm
Max Speed: 120piece per minute
Back Out Length: 50mm
Main Power: 15KW
Net Weight: 11000KG
Dimension: 3500*2200*1500mm
cold forging machine: on working
China Automacold forging machine:finished products samples
cold forging machine: loading into container(export to Russia)
Welcome to visit our cold forging machine in factory and Shanghai, China.
