CCY P10 Outdoor Full Color Led Advertising Board

CCY P10 Outdoor Full Color Led Advertising Board thumbnail-1
CCY P10 Outdoor Full Color Led Advertising Board photo-1
US$ 800 - 1,600 MOQ: 1 Square Meter
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
CCY
Model Number:
CCY-OF-P10mm
Contact Supplier Request Quote Chat Now
Shenzhen CreKing Electronics Technology Co., Ltd.
Gold Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name CCY
Model Number CCY-OF-P10mm
Usage Outdoor
Tube Chip Color Full Color
Display Function Video
Pixels 10mm

Specifications

P10 outdoor full color led advertising board
>High brightness
>Low power and voltage
>Wide viewing angle
>Water-proof

CCY P10 outdoor full color led advertising board

 Let me give you a brief introduction about my company, we CCY which specializie in indoor and outdoor full color led display and other Peripheral LED product with 8 years, now our factory was 15000sqm, has 5 floors, the 5th floor is office, the 4th is for LED tube encapsulation, and 1st to 3rd floors for assembling and test. We are one of the 5 biggest factory of encapsolution in shenzhen China, we hav been adopting the 12 full automatic die boonders of Japanese’s Panasonic equipment to producing our led tube, 6 the USA modern AMS DIP manchines, 3 big SMT manchines (import from Korea Sunsung), 2 Juki high temperature wave-soldering machine, and 1 RF-H880 Reflow Soldering Machine, 4 red rays QC machines, Wuto silicon sealing machine, evern-power mask putting machine, all of which makes sure that we have a production capacity of 5000 sqm per month of good quality and delivery time what is promised.





We do the LED encapsulation by ourselves (Quality is under strict control, prices are very competitive).

  1. We are professional and only concentrate on outdoor and indoor LED video displays.
  2. Fast and punctual delivery. With full of advanced auto machines and well-trained workers, our delivery is always on time.
  3. After-sales service. Our after-sales engineers have been in LED field for more than ten years who is sophisticated in programming all kinds of control systems, extending professional maintenance or repairing skills to customers.



parameters and module

1. Pixel Pitch 10 mm

2. Virtual pixel pitch 5mm

3. Density per sqm 10000 pixels

4. Pixel configuration: 1R1G1B

5. LED package DIP 346

6. Module resolution 16 dots*16 dots

7. Module size 160 mm*160 mm

8. Cabinet size 1280 mm*960 mm

9. Whiteness brightness ≥8000

10. Grey Scale/Color: Display colors≥16.7m

11. Best Viewing Distance 8m~65m

12. Driving method: static constant current , 1/4 Scan  Constant Current,

13. View Angle (H) 110°~140°(V)/ 55°

14. Frame frequency 60 Hz

15. Refresh Rate 450 Hz

16. Max power 700W/sqm

17. Average power 300W/sqm

18. Protection classification IP65 front/IP54 rear

19. Cabinet Weight  about 40 Kg

20. Install mode Wall mount, hung and stand structure

21. Cabinet Material Iron/Aluminum

22. Working voltage AC 110~220v/±10%

23. Control method: Synchronization

24. Malfunction dot rate  Less than 0.0001

25. Working temperature -20~60°C

26. Working Humidity 10~95%

27. Lifetime 100,000 hours

28. MTBF  ≥ 10000 hours

29. Whole display flatness: less than 1mm juncture

30. Transmission distance  LAN cable ≤ 100m,  optic fiber transmission: MMF ≤500m, SMF ≤15km

  CCY P10 outdoor full color led advertising board

 CCY P10 outdoor full color led advertising board

certificate

                                          CE and ROHS

CCY P10 outdoor full color led advertising boardCCY P10 outdoor full color led advertising boardCCY P10 outdoor full color led advertising board
