China Shenzhen led digital clock display
- 5000 Square Meter / Square Meters per Month
- Shenzhen
- T/T Credit Card
- P10 outdoor electronic display dynamic billboard
- P20 high quality bus-station multi-color led display
- P16mm guangzhou led outdoor display screen
- outdoor big curved display led outdoor full color
- P12 multi color led display outdoor screen for tourism
- p12mm stadium led display screen outdoor three color
Product Details
Place of Origin: | Guangdong, China | Brand Name: | CCY | Model Number: | CCY-OF-P10mm |
Usage: | Outdoor | Tube Chip Color: | Full Color | Display Function: | Video |
Pixels: | 10mm |
Packaging Details
packing:(optional)
1. wooden case
2. flight case
Product Description
Specifications
China Shenzhen led digital clock display1)High brightness
2)Low power and voltage
3)Wide viewing angle
4)Water-proof
China Shenzhen led digital clock display
1)High brightness
2)Low power and voltage
3)Wide viewing angle
4)Water-proof
CCY led display advantages are:
- We do the LED encapsulation by ourselves (Quality is under strict control, prices are very competitive).
- We are professional and only concentrate on outdoor and indoor LED video displays.
- Fast and punctual delivery. With full of advanced auto machines and well-trained workers, our delivery is always on time.
- After-sales service. Our after-sales engineers have been in LED field for more than ten years who is sophisticated in programming all kinds of control systems, extending professional maintenance or repairing skills to customers.
1. Pixel Pitch 10 mm
2. Virtual pixel pitch 5mm
3. Density per sqm 10000 pixels
4. Pixel configuration: 1R1G1B
5. LED package DIP 346
6. Module resolution 16 dots*16 dots
7. Module size 160 mm*160 mm
8. Cabinet size 1280 mm*960 mm
9. Whiteness brightness ≥8000
10. Grey Scale/Color: Display colors≥16.7m
11. Best Viewing Distance 8m~65m
12. Driving method: static constant current , 1/4 Scan Constant Current,
13. View Angle (H) 110°~140°(V)/ 55°
14. Frame frequency 60 Hz
15. Refresh Rate 450 Hz
16. Max power 700W/sqm
17. Average power 300W/sqm
18. Protection classification IP65 front/IP54 rear
19. Cabinet Weight about 40 Kg
20. Install mode Wall mount, hung and stand structure
21. Cabinet Material Iron/Aluminum
22. Working voltage AC 110~220v/±10%
23. Control method: Synchronization
24. Malfunction dot rate Less than 0.0001
25. Working temperature -20~60°C
26. Working Humidity 10~95%
27. Lifetime 100,000 hours
28. MTBF ≥ 10000 hours
29. Whole display flatness: less than 1mm juncture
30. Transmission distance LAN cable ≤ 100m, optic fiber transmission: MMF ≤500m, SMF ≤15km
certificate
CE and ROHS
