MW/CL Power Supply Led Screen

US$ 800 - 2,000 MOQ: 1 Square Meter

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

CCY

Model Number:

Shenzhen CreKing Electronics Technology Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name CCY

Model Number p6

Usage Outdoor

Tube Chip Color Full Color

Display Function Video

Pixels Other, 6mm

Specifications

MW/CL power supply led screen
1-brightness >2500cd/m2
2-ce ul ccc fcc
3-best after service
4-lifespan 100,00

MW/CL power supply led screen

-high brightness with high clear screen

-long lfe and lower consumption

-high viewing angle

-gold after service

p6 indoor led billboards(3IN1)

Indoor full color series

CCY-IR.-P6

MW/CL power supply led screen parameters

Product No.	P4	P6	P7.62	P10	P12
Physical pixel pitch	4mm	6mm	7.62mm	10mm	12mm
Physical pixels per sqm	62500	27777	17222	10000	6944
Pixel constitution	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B
Cabinet size	512*512mm	768*576mm	976*732mm	1280*960mm	768*576mm
Cabinet weight	18kg	30kg	40kg	56kg	30kg
Cabinet resolution	128*128pixels	128*96pixels	128*96pixels	128*96pixels	64*48pixels
Best viewing distance	4m	6m	7.5m	8m	10m
Max. power consumption	1400W	1100W	700W	800W	750W
Ave.power consumption	350W	2800W	180W	200W	170W
Brightness	≥2000CD/m2	≥1500CD/m2	≥1200CD/m2	≥1500CD/m2	≥1000CD/m2
Driving method	1/8scan constant current driving			1/4scan constant current driving
Best viewing angle	Horizontal: ≥120°; Vertical: ≥120°
Frame frequency	≥60Hz/s
Refresh rate	≥400Hz/s
Color	281 trillions
Input voltage	AC 110 or AC220 V ±10% ,50 to 60Hz
MTBF	10,000 hours
Life-span	100,000 hours
Ingress protection	Front IP31
Working environment	Temperature: -20°C-50°C; Humidity: 10%-90%RH
