Specifications
architectural lighting outdoor led lights wall washer;DMX512 Control Signal ;
18*3W high power 3 in 1 LEDs;
IP65,CE & RoHS;
Factory supply directly! architectural lighting outdoor led lights wall washer
M-L054X4-RGB(3 in 1) architectural lighting outdoor led lights wall washer is a mixture of red, green and blue to produce, via RGB electronic mixing, an endless palette of attractive pastel or deep colors, which has a multitude of benefits including silent operation, durability, long service life, high efficiency at electro-optic transfer, and low power consumption with compact size.
The LED wall washer uses DMX512 signal to control its colors and brightness. It is widely used at supermarket, Disco, shopping center, architectural building, hotel, garden and theater, etc.
Specification and Parameter
| Technical DataModel | Outdoor LED wall washer M-L054X4-RGB(3 in 1) |
| Power Supply | AC220±10%, 50Hz(AC110±10%, 60Hz available) |
| Power Consumption | 54W max |
| Light Source | 18*3W high power 3 in 1 LEDs |
| Beam Angle | 30° |
| Illumination intensity | 4620Lx@ Lm(25°) |
| Control Channels | 5/7/11 |
| Control Signal | DMX512,Auto Mode,Master/Slave Mode |
| Input signal | XLR4-Pin(In & Out) |
| Combined safety design | patent techonology |
| working temperature | -20°C~ 40°C |
| Protection Grade | IP65 |
| Dimension | 880mm×76mm×132mm |
| Net Weight | 4kg |
| Material | aluminium extruded sections |
| Light source useful time | 50,000hrs |
| Strobe | 0.3~ 15flash/sec |
Item Pictures:
Features:
This item with 18 pc high power leds, much better brightness.
LED light series designed for professional stage and architectural lighting applications, it incorporates high power LED with 3 different basic colors: red, green and blue, it is easy to mix them into a color spectrum to create virtually unlimited selection of colors. With light source of LED, this fixture has following advantages:
1. Long service life, service life is 50000 hours under nominal working conditions, and only 5% decrease in the first 1000 working hours;
2. Bright colored, color saturation can be reached at more than 90% to produce more brilliant light effects;
3. High efficiency and low power consumption. There is no color filter loss, being efficient at electro-optic transfer;
4. RGB color mixing with or without DMX control;
5. Environmental protected, since there is no ultraviolet radiation and infrared ray in the spectrum, it is low at heat emission and radiation;
6. With a build-in stand alone function and master / slave mode available;
7. Current protection to PCB panel and over-heat protection;
8. 64 sub-ID codes addressing panel available in one DMX address.
With aluminum alloy housing, our LED light is of excellent quality and good durability. It is designed for both indoor and outdoor applications and typically used as a down light for stages or illumination of specific points of interest such a performer, status, buildings, and disco, etc. it is widely used at entertainment places, such as dancing hall, architectural building, discos, pubs, theaters, shows and clubs, etc.
Lighting effect & Successful case
M-L054X4-RGB(3 in 1) Case -Qianzhou Ancient City Lighting project
CE certified:
LED Light Workshop
Established in 2001, we are a professional manufacturer of stage lights and LED display, we have 6 product lines including LED Lights, Moving heads, cool lights, effect lights, color scrollors and special LED display plant, products are normally CE & Rohs certified.
And we are the member of China Entertainment Technology Association, of Seminar of China Television Broadcasting Institution, and of Society of China Illumination. Our ISO 9001 / 2008-certified factory has more than 200 workers and over 30 R&D staffs.
Company showroom
Contact us
Company Name: Hunan Minghe Opto Tech Co., Ltd.
Street Address: NO 2. Xiang Yang Road, Changsha National Economic Development Zone,Hunan,China
Zip: 410100
Telephone: 0086-731-85252378
Fax: 0086-731-84029869
