Specifications
outdoor building lighting led city color lightDMX512 Control Signal
56 Red, 56 Green, 48 Blue
CE & ROHS certified
160 high power 3W LEDs outdoor building lighting led city color light
M-TL3H-RGB LED city color outdoor building lighting is a mixture of red, green and blue to produce, via RGB electronic mixing, an endless palette of attractive pastel or deep colors, which has a multitude of benefits including silent operation, durability, long service life, high efficiency at electro-optic transfer, and low power consumption with compact size.
The LED wall washer uses DMX512 signal to control its colors and brightness. It is widely used at supermarket, Disco, shopping center, architectural building, hotel, garden and theater, etc.
Specification and Parameter
| LED city color M-TL3H-RGB |
| Power Supply: AC220±10% 50Hz (AC110±10% 60Hz available) |
| Power Consumption: 480W max |
| Light Source: 160 high power 3W LEDs (56 Red, 56 Green, 48 Blue) |
| Beam Angle: 45° |
| Illumination Intensity: 28600 Lx@1m |
| Pan Adjustment: 0~30° |
| Tilt Adjustment: 0~90° |
| Control Signal: DMX512, Auto Mode, Master/Slave Mode |
| Control Channels: 5/7/11 |
| Input Signal: XLR 4-Pin (In & Out) |
| Working Temperature: -20°C~40°C |
| Protection Grade: IP44 |
| Dimension: 500mm×400mm×480mm |
| Net Weight: 35 kg |
Item Pictures:
Features:
This item with 160 pc high power leds, much better brightness.
LED light series designed for professional stage and architectural lighting applications, it incorporates high power LED with 3 different basic colors: red, green and blue, it is easy to mix them into a color spectrum to create virtually unlimited selection of colors. With light source of LED, this fixture has following advantages:
1. Long service life, service life is 50000 hours under nominal working conditions, and only 5% decrease in the first 1000 working hours;
2. Bright colored, color saturation can be reached at more than 90% to produce more brilliant light effects;
3. High efficiency and low power consumption. There is no color filter loss, being efficient at electro-optic transfer;
4. RGB color mixing with or without DMX control;
5. Environmental protected, since there is no ultraviolet radiation and infrared ray in the spectrum, it is low at heat emission and radiation;
6. With a build-in stand alone function and master / slave mode available;
7. Current protection to PCB panel and over-heat protection;
8. 64 sub-ID codes addressing panel available in one DMX address.
With aluminum alloy housing, our LED light is of excellent quality and good durability. It is designed for both indoor and outdoor applications and typically used as a down light for stages or illumination of specific points of interest such a performer, status, buildings, and disco, etc. it is widely used at entertainment places, such as dancing hall, architectural building, discos, pubs, theaters, shows and clubs, etc.
Lighting effect
CE certified:
LED Light Workshop
About MHG
Established in 2001, we are a professional manufacturer of stage lights and LED display, we have 6 product lines including LED Lights, Moving heads, cool lights, effect lights, color scrollors and special LED display plant, products are normally CE & Rohs certified.
And we are the member of China Entertainment Technology Association, of Seminar of China Television Broadcasting Institution, and of Society of China Illumination. Our ISO 9001 / 2008-certified factory has more than 200 workers and over 30 R&D staffs.
