Home > Consumer Electronics > LED Display > Indoor LED Display > Outdoor Curve Led Screen

Outdoor Curve Led Screen

US$ 700 - 1,900 MOQ: 3 Square Meters

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

CCY

Model Number:

CCY-O-F-P16mm

Contact Supplier Request Quote Chat Now

Shenzhen CreKing Electronics Technology Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name CCY

Model Number CCY-O-F-P16mm

Usage Outdoor

Tube Chip Color Full Color

Display Function Video

Pixels 16mm

Specifications

CCY outdoor curve led screen
1) high contrast design
2) Low voltage and power consumption
3) Advanced and mature technology

CCY's outdoor curve led screen character:

Arc LED display change the traditional LED light-emitting diodes arrangement,changed the signal display mode from the General signal level transmission to the Vertical signal mode,The key technologyof the arc screen in reducing unit panel’s curvature, to enhance the waterproof performance and the perspective of contunuity,Each unit boxis processed by the entirely digitized engine bed to ensure the accuracy of design Requirements, This arc screen now has been exported and installed in foreign countries. Its good visual effects had won a lot of consumers praise.

CCY's whole Screen Aging, must passed 72 hours, then allow to ship to our client

PRODUCT NAM: PH16 Outdoor curve full color/ Virtual

Product category: Outdoor full color series

PRODUCT NUMBER: CCY-O-A-P16mm

PH16mm Curve Outdoor full color led display screen
ITEM	PARAMETER	UNIT
Pixel pitch	16	mm
Pixel density	3906*4	dot/m2
Pixel configuration	2R1G1B	-
LED specification	¢ 5 ellipse
Driver mode	Constant current driver, dynamic state/static scaned	-
Display bightness	≥6800	cd/m2
View angle	Horizontal: ≥140°; Vertical: ≥120°	deg.
Panel pixel	16×8	dot
Panel dimension	256×128*30	mm
Unit box pixel	64*48	H*V
Box dimension	1024×768×125	mm
Refresh frame frequency	adjustable from 10Hz to 3000Hz	Hz
Display colors	16.7M	color
Grey scale	adjusted:409640964096	grade
Power consumption	max:1200;ave:300	w/m2

Remark:

1) Quotation valid time: 30 days (because the exchange rate Dollar to RMB)

2) Delivery date is 28days (construction date is 25days, testing date is 3days)
(calculate from we confirm receiving the deposit from the bank account)

3) Control system = Data collect and sending card+ Receiving and drive card+ Display card

4) Cabinet material: Cold rolled steel; each cabinet: waterproof

5) Spare parts: according to the 0.03 ratios,

6) Payment method: T/T 50% before production as earnest, balance T/T 50% before delivery

7) Guarantee time: Our warranty date is one year with free charge as guaranty date, during that date, if your display screen has problem (caused by display-selves quality), we will maintain the screen for you with free by telephone or internet, if the malfunction caused by the person-intentionally ,and caused large-scaled damage ,then we will charge based on the cost ,

8) Over the guaranty date, we will maintain and serve for you always, but we have to charge based on the damage parts cost,
whenever you need engineer to maintain the screen ,all have to pay the engineer two round way ticket ,lodge and board fee ,and other related transportation fee in your country , and if over the warranty date ,besides the ticket ,room and board fee ,you have to pay engineer one day USD100 each person for their working ,

9) Installation: usually we don’t responsible for the installation on the site, customer provide the installation place pictures and tell us the detailed requirement after sign the contact, then our company will provide the diagram for installation and screen connection, then customers will install the screen according to our diagram, if you want to invite our engineer to guide the installation for you is ok too,
By the way, the fame which support Led screen stand on the road or other republic places often prepared by the customer selves, you can let your local advertisement company or decoration company to tailor-made for you ,

10) Training manner : we will train one engineer for you at least by long-distance control in internet and phone or you can send one engineer to our factory to accept the training one week or you invite our engineer to guide installation and train one engineer for you in your country ,

(You could send your staff who have some knowledge of electricity and computer to our factory and we will provide free training of how to maintain and repair.) Training time is one week,

11) Meeting: Each month, our company will have one meeting for the customers, consulting good ideas together for solving led signs problems during using , and new led signs exploring in the market ,we care closely the led signs development and improvement ,join together with each customer ,ready well to providing you strong technology support anytime !
