Home > Consumer Electronics > LED Display > Indoor LED Display > Shenzhen Factory P12.5 Mesh Led Display/curtain Led Display/gridding Led Display Screen/indoor Outdoor Led Display Screens

Shenzhen Factory P12.5 Mesh Led Display/curtain Led Display/gridding Led Display Screen/indoor Outdoor Led Display Screens

Name: Shenzhen Factory P12.5 Mesh Led Display/curtain Led Display/gridding Led Display Screen/indoor Outdoor Led Display Screens
Brand: Creking
SKU: 106807461
Availability: InStock

Shenzhen Factory P12.5 Mesh Led Display/curtain Led Display/gridding Led Display Screen/indoor Outdoor Led Display Screens thumbnail-1

Shenzhen Factory P12.5 Mesh Led Display/curtain Led Display/gridding Led Display Screen/indoor Outdoor Led Display Screens photo-1

US$ 900 - 3,500 MOQ: 25 Square Meters

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Creking

Model Number:

Creking-OF-P16

Contact Supplier Request Quote Chat Now

Shenzhen CreKing Electronics Technology Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Creking

Model Number Creking-OF-P16

Usage Outdoor

Tube Chip Color Full Color

Display Function Video

Pixels 16mm

Screen Dimension 25

Specifications

Shenzhen factory P12.5 mesh led display/curtain led display/
gridding led display screen/indoor outdoor led display screens

1 Shenzhen factory P16 full color Chinasupplier alibaba full color LED curtain led curtain display screen modules / led curtain stage P12.5 mesh led display/curtain led display/gridding led display screen/indoor outdoor led display screens details:

2. Shenzhen factory P12.5 mesh led display/curtain led display/gridding led display screen/indoor outdoor led display screens Specification : Technical data for outdoor full color led displays modules details:

specification	P8	P10	P12	P16	P18	P20	P25	P31.25
Led composition	1R1G1B	1R1G1B	1R1G1B	2R1G1B	2R1G1B	2R1G1B	2R1G1B	4R2G1B
Real pixel (pixel/sqm)	15625	10000	6944	3906	3086	2500	1600	1024
Pitch size	8mm	10mm	12mm	16mm	18mm	20mm	25mm	31.25mm
Brightness(>cd/sqm)	>6000	>5000	>4500	>6500	>6000	>5500	>4500	>2500
Max Power consumption(Wsqm)	1500	1000	800	1000	850	650	500	300
Driving mode	1/4scan,constant current			Static , constant current
Gray Scale	256 prades linear input,16384 grades output adjustable,100 grades brightness adjustable
Refresh rate	400Hz/s
communication distance	Common distance 100M(Fiber optic transmission 15000M)
Displaying color	16.7Million
Life span	>50,000 Hours
Operation temperature and humidity	-20 °C~45°C ,10%~95%
Operation voltage	110-220V, plus-minus 10%

3.shenzhen Creking China supplier outdoor full color led curtain display screen,bus led display,station display,big stadium screen and curtian LED display screen another details:

1. Lock button
2. Hanging cabinets inner structure
3. Hanging beam
4. Bottom Bracket
5. Flight case

6.CE, ROHS,FCC,CCC,ISO9001:2008 ,UL

4. Shenzhen factory full color led curtain display screen modules Indoor led video displays modules screen parameters :

specification	P3	P4	P5	P6	P7.62	P10	P12.5grid
Led composition	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B
Display resolution (pixel/sqm)	111111	62500	40000	27777	17222	10000	6400
Pitch size	3mm	4mm	5mm	6mm	7.62mm	10mm	12.5mm
Brightness(>cd/sqm)	>2000	>1600	>1500	>1400	1200	1000	>800
Max Power consumption(W/sqm)	1800	1500	1000	1200	850	500	400
Operation temperature and humidity	-20 °C~45°C ,10%~95%
Operation voltage	110-220V,plus-minus 10%

4. Shenzhen factory P12.5mm Full color outdoor led curtain display mesh led display/curtain led display/gridding led display screen/indoor outdoor led display screens descriptions:

>>>Controlled and opertaed by computer

>>>new full color Display what copmuter can display at the same time

>>>IP65 outdoor full color

>>>Modular design for easy assemble

5.Shenzhen Electronics factory led creking Electronic full color outdoor led display Screen factory details as follow:

We can be available varirties of full color commercial led displays,stage full color led screen,special-shaped led display screen ,stadium full color led display board,rental full color led display screen modules,ect.

Welcome to visit to Shenzhen indoor/outdoor full color shenzhen led Creking Electronics company.
