Home > Consumer Electronics > LED Display > Indoor LED Display > SMD Full-color 3 In1 Indoor Screen(PH12)
SMD Full-color 3 In1 Indoor Screen(PH12)
US$ 1,000 - 2,000
MOQ: 1 Cubic Inch
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
MHG
Model Number:
PH12
Payment & Shipping
Payment Methods:
Port of Shipment:
Changsha
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Dimmable P3.91 SMD Indoor Die-casting Aluminum LED PanelUS$ 900 - 1,100MOQ: 5 Square Meters -
China High Quality P3.91 SMD Indoor Die-casting Aluminum LED Screen for RentUS$ 900 - 1,100MOQ: 5 Square Meters
-
Super Resolution P3.91 SMD Indoor Die-casting Aluminum LED Panel DisplayUS$ 900 - 1,100MOQ: 5 Square Meters
-
Advertising P3.91 SMD Indoor Die-cast Aluminum Led DisplayUS$ 900 - 1,100MOQ: 5 Square Meters
-
Commercial P3.91Indoor Die-cast Aluminum Led ScreenUS$ 900 - 1,100MOQ: 5 Square Meters
Place of Origin
Hunan, China
Brand Name
MHG
Model Number
PH12
Usage
Indoor
Tube Chip Color
Full Color
Display Function
Video
Pixels
11mm
Screen Dimension
Customized Size
Established in 2001, the member of China Entertainment Association,is a professional manufacturer of LED display,stage lighting. All of our products passed the ISO9001:2000 ,3C,CE,FCC,ROHS,LVD ...certifications .
MHG PH12 Indoor full color LED Display (SMD 3-in-1)
1.High resolution,low power consumption, large viewing angle and long lifespan
2.This modle Widely used in advertising, sports, industrial enterprises, transportation, stations, terminals, airports, construction, education system and other public places until now.
MHG LED DISPLAY SMT WORKSHOP:
Specifications:
| LED DISPLAY TYPE | PH12 SMD FULL 3 in 1COLOR SERIES (INDOOR) | ||
| Pixel pitch | 12mm | Frame frequency | 60-85HZ |
| Physical density | 6944 pixels/sq | Refresh rate | 240-1000HZ |
| LED configuration | SMD 3 in 1 | Brightnessd adjustment | 0-100% 8 levels automatic |
| Physical density | 1R1G1B | Gamma correction | -5.0-5.0 |
| Module size | 1192*192mm | Correction scale level | 16bits |
| Module resolution | 16*16 | Color temperature | 5000-9300k |
| Drive mode | Dynamic 1/8 duty ty constant current |
Brightness correction | Pixel,module, cabinet correction |
| Brightness | ≥1100cd/m2 | Contrast | ≥2000:1 |
| Control distance | UTP CAT5E:100m,muti-mode fiber:500m single-mode fiber:10km |
Input source support | composite,S-video,component, VGA,DVI,HDMI,SDI,HD SDI |
| View angle | 140./140. | Operating temperature | -40-60.C |
| Minimum view distance | 12m | Operating humidity | 10-90% RH |
| Grey scale | 10bits/1024 levels | Operating life span | 100,000 Hours |
| Color capacity | 1.07 billion | MTBF | 5000 hours |
| Maximum power consumption | 600w/ M2 | Protection ratings | IP31 |
| Ave power consumption | 200w/M2 | Out of control rate | 0.01% |
| Operationg power source | AC90-260V 50-60 HZ | ||
MHG SUCCESSFUL CASES:
