Transparent /glass/curtain Video Led Wall

Name: Transparent /glass/curtain Video Led Wall
Brand: CreKing
SKU: 106807023

US$ 900 - 1,000 MOQ: 12 Square Meters

Key Specifications

Place of Origin:

China

Brand Name:

CreKing

Model Number:

CR-IC-P12.5

Shenzhen CreKing Electronics Technology Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

ShenZhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name CreKing

Model Number CR-IC-P12.5

Usage Outdoor

Tube Chip Color Full Color

Display Function Video

Pixels Other, 12.5mm

Screen Dimension customized

Specifications

Transparent /glass/curtain video led wall
1) 40% transparaency
2) Modular design
2)stage background

Transparent /glass/curtain video led wall

P12.5 mm indoor curtain led screen technical parameter :

Parameter	Unit	Value
Pixel Pitch	mm	12.5
Brightness	nits	1500
Colour temperature	deg. K	6500
Contrast ratio		1000:1
Viewing angle - Horizontal (50% brightness)	deg.	140(+70 / -70)
Viewing angle - Vertical (50% brightness)	deg.	120(+60 / -60)
Recommended minimum viewing distance	m	12
Pixel matrix per panel		40x40
Panel size	mm	500x500x50
Panel material		PC + AL
panel weight	Kg	4.8
Ingress protection(front/rear)		IP65/ IP65
ltransparency		25 %
Pixels per sq. meter		6400
Pixel type and configuration	R/G/B	1/1/1
Refresh rate		>1000
Gray scale(linear)	Levels	14bit
Brightness control	Levels	255
Panel input format		Proprietary SDI, RGBHV, YUV, YC, Composite
Input voltage(nominal)	VAC	110 to 240
Input power frequency	Hertz	50 to 60
Input power (Max)	Watts	150
Input power (Average)	Watts	60
Operating temperature range	deg. C	-20 to +55
Lifetime (50% brightness)	Hours	≥100,000
Rigging system		Fixed or Hangering system
