Help Center5.1CH Digital Audio Decoder With USB Multi-Media
Related Products
-
Digital Audio Decoder to Analog With SPDIF/Toslink 3X1 SwitcherNegotiableMOQ: 50 Pieces -
HDMI Surge Protector Screen ProtectorNegotiableMOQ: 100 Pieces
-
Hdmi Hdtv Adapter ForGoogle Nexus 4/ LG Optimus G Pro/ Fujitsu Arrows Tab/ ASUS Padfone Infinity.NegotiableMOQ: 200 Sets
-
Hdmi Hdtv Adapter for Google Nexus 4/ LG Optimus G Pro/ Fujitsu Arrows Tab/ ASUS Padfone Infinity.NegotiableMOQ: 200 Sets
-
Hdmi Hdtv Adapter for Google Nexus 4/ LG Optimus G Pro/ Fujitsu Arrows Tab/ ASUS Padfone Infinity.NegotiableMOQ: 200 Sets
Specifications
wo-Ports SPDIF (1 x Optical and 1 x Coaxial) digital audio input, one USB2.0 interfaceSupport for multiple EQ model
FEATURES:
l Two-Ports SPDIF (1 x Optical and 1 x Coaxial) digital audio input, one USB2.0 interface. You can
switch freely between different signal sources.
l Output 5.1 channel analog audio and 1 x CVBS , can be connect to the amplifier or TV
l Uses 24 bit/96KHz audio DSP and 24bit /192KHz DAC
l Support for multiple EQ model
l Support digital audio formats: Dolby digital (AC3), DTS, LPCM
l Support multimedia playback of USB disk, can play music, video, photo and text files
l The USB port can provide charging for mobile devices
l Automatic identification input digital audio signal format, automatic track test
l Support stereo and 5.1 channel two output modes, can be flexible with speaker
l High tone quality, low noise
l One button to switch mode, simple to operate.
l Support for remote operation, visual menu interface
l Power-off memory
l DC5V/1A power adapter
SPECIFICATIONS: ADSW0007M1
Digital audio decode format……………………………………………….Dolby Digital (AC3)/DTS/LPCM
USB playback music format……………………………………………………...MP3 / WMA / AAC / WAV
USB playback video format…………… Divx3.11,4.x,5.x/Xvid/AVI/MJPEG/VOB/VCD(Dat)/MPG1,2,4
USB playback photo format……………………………. JPG (Resolution range: 16x16~10000x10000)
DSP sample frequency range………………………………………………………………….. 32~96 KHz
DSP Bit rate range………………………………………………………………………………….16~24 Bit
Digital input level……………………………………………………………………………….0.1~1Volts p-p
Analog output level(1kHz@0dB)...............................................................................................1V RMS
SNR @ 0dB(CCIR/ARM)………………………………………………………………………………≥85dB
Distortion………………………………………………………………………………………………..≤0.1%
Frequency response…………………………………………………………………………….20Hz~20KHz
Max working current …………………………………………………………….……….…….….…..400mA
Power adapter format Input ……......….….…….…….…….…. AC 100V~240V 50HZ/60Hz, DC5V/1A
Operating Temperature range ……..…………….……………………………………………. -10 to +55°C
Storage Temperature range……………………………………………………………………. -20 to +60°C
Operating Humidity range ………………………….….……….……….10 to 90%RH (No Condensation)
Storage Humidity range………………………….….……….……………5 to 95%RH (No Condensation)
Case Dimension (L x W x H) ………………………………….………………………….. 139x64x22 (mm)
Weight …….…………………………….………………………………………….……………………. 210g
