Specifications
One VGA+RL input or One VGA+SPDIF input change to One HDMI SignalSupport video input : VGA analog
FEATURES
lOne VGA+RL input or One VGA+SPDIF input change to One HDMI Signal
lSupport video input : VGA analog
lSupport Audio Input: RL Analog Signal, SPDIF Digital Signal.
lHDMI output : Support up to 1920x1080@60HZ
lSupport VGA input: 800x600@60HZ,800x600@75HZ,1024x768@60HZ, 1024x768@75HZ 1152*864@60HZ,1152x864@75HZ,1280*720@60HZ,1280x768@60HZ,1280x800@60HZ,
1280x960@60HZ,1280x1024@60HZ,1280x1024@75HZ,1360x768@60HZ,1366x768@60HZ,1440x900@60HZ,1600x1200@60HZ,1680x1050@60HZ,1920x1080@60HZ
lHDMI output resolution:720P/ 60Hz. 1080P/ 60Hz;
lAdaptive PAL / NTSC standard.
lIt can choose the SPDIF audio or RL audio input by use the manual button.
lThe HDMI Output cable length can support up to 15M if use the standard AWG26 HDMI Cable.
llow-power digital single chip solution, less heat and long time stability
lEasy to Install and Automatically Check the input signal
lIt can do power supply by the Micro USB Power Supply Port
Support input……………………………………….………………………………………….. VGA
Support up to VGA ……………………………………………………………1920×1080@60Hz
HDMI output resolution…………………………………………...…….……720P/1080P@60Hz
Support resolution up to………………………………………………..…………………1250lines
Max refresh rate………………………………………………………………..……………….75HZ
Input Video signal ………….……………………..………………………………0.5~2.0Volts p-p
Output video signal……………………………………….……………………-0.35~0.7Volts p-p
Max working current……………………….………………………………………..............300mA
Input cable distance……………………………………………………≤15m VGA standard cable
Output cable distance…………….…..…….….................. ≤20m AWG26 HDMI standard cable
MICRO USB Power Standard……………………………………………………………5V/500mA
Operating Temperature range………………………………………………….……… 0 to +40°C
Operating Humidity range…………………………….……… 5 to 85%RH(No Condensation)
Dimension (L x W x H)………………………………….……………….…….. 64X64X25.5 (mm)
Weight…..………………………………………………….……..……..……………..……….. 85g
Notes:
Pls use the machine as the instruction listed to keep the long use lifetime of the machine.
- 1. The machine should be placed at the spot far from the Damp, High-Temperature, Dusty, Erosive, and oxidative environment.
- 2. All parts will be free from the strong shake, hit, fall.
- 3. Touching the power adaptor with the wet hands is prohibited.
- 4. Pls hold the power adaptor head and do not pull the power cord when cut off from the socket.
- 5. Pls turn the power off when the machine is not used for long time.
- 6. Pls do not open the cover and do not touch the inside parts.
-
7. Pls use the original factory power adaptor.
