3mm cheap price photo cell GL3547-1

Specifications

3mm LDR GL3547-2
1.Small volume
2.High sensitivity
3.Fast response Good reliability
4.Good spectrum characteristic

3mm CDS Light Dependent resistor     GL3547-1



Photoresistor is a resistor which made of semi-conductor material,and the conductance changes
with luminance variation .The photoresistor can be manufactured with different figures and illuminated
area based on this characteristic.Photoresistor is widely used in many industries, such as
toys,lamps,camera,etc.



Performances and Features

Coated with epoxy

Good Reliability

High Sensitivity

Small Volume

Fast Response

Good Spectrum Characteristic



Applications

Switch

Light control

Electronic toy

Light control lamp

Photoelectric control

Industrial control

Camera automatic photometry

Annunciator



Specification

Specification	Type	Max Voltage (VDC)	Max power (mw)	Environmental temperature	Spectrum peak value     (nm)
φ3 series	GL3516	100	50	-30~+70°C	540
	GL3526	100	50	-30~+70°C	540
	GL3537-1	100	50	-30~+70°C	540
	GL3537-2	100	50	-30~+70°C	540
	GL3547-1	100	50	-30~+70°C	540



Specification	Light resistance (10Lux) (KΩ)	Dark resistance (MΩ)	r100/10	Response time (ms)		Illuminance resistance characteristic
				Increase	Decrease
φ3 series	5-10	0.6	0.5	30	30	2
	10-20	1	0.6	30	30	3
	20-30	2	0.6	30	30	4
	30-50	3	0.7	30	30	4
	50-100	5	0.8	30	30	6
