China Manufacturer PE100 Gas Pipe, HDPE Price Gas Pipe
US$ 2 - 150
MOQ: 50 Meters
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
MAX
Model Number:
HDPE PIPE
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hot Sale PE100 HDPE Gas Pipe Specifications 20MM to 630MMUS$ 0.5 - 800MOQ: 100 Meters -
High Density Polyethylene Natural Gas Piping/Pipes for Oil and GasUS$ 0.5 - 500MOQ: 100 Meters
-
Underground Natual Gas Supply Poly Gas PipeUS$ 0.5 - 500MOQ: 100 Meters
-
Hdpe Pipe for Oil and Gas/plastic pe PipeUS$ 1 - 200MOQ: 100 Miles
-
HDPE Oil and Gas Pipe pe FittingsUS$ 1 - 200MOQ: 100 Miles
Place of Origin
Henan, China
Brand Name
MAX
Model Number
HDPE PIPE
Material
PE
Specification
20mm-1400mm
Length
6m, 12m or as required
Thickness
2mm-82mm
Standard
ISO9001 CE certificate
Specifications
price gas pipeMaterial: PE80, PE100
PN Grade: SDR17.6 PN<=6,SDR11 PN<=10
working temperature: -20~40 degree
China Manufacturer PE100 Gas pipe, HDPE Price Gas pipe
HDPE Gas Pipe Features:
1.Pressure Rating: SDR17.6 PN<=6 SDR11 PN<=10
2.Size: from 20mm to 1200mm available
3.Standard: GB15558.1-2003
4.Colors: Yellow, Black with yellow stripes, other colors available on request
5.Standard: ISO4427 EN12201 ASTMD714 AS4130 GB/T13663
6.Certification: ISO9001, CE certification.
HDPE Gas Pipe Applications:
1.PE gas pipe is suitable for gas transportation on condition that working temperature is among -20°c~40°c
2.Long-term maximum working pressure is not more than 0.7MPa.
3.Polyethylene Gas Pipe is suitable for Gas distribution network both for domestic & industrial consumption.
HDPE Gas Pipe Advantages:
1.Non-toxic, health:PE pipe material non-toxic, tasteless, through the strict health monitoring,
it belongs to green building materials, never scaling, which can effectively improve the water quality.
2.Corrosion resistance:PE belongs to inert materials, can resistance to various chemical media.
3.No leakage:PE pipe is connected by electric melting, its interface strength higher than tube itself .
4.High toughness:fracture extension rate of PE pipe,commonly more than 500%.As to the uneven settlement of the base, its adaptive ability is very strong, good aseismic performance.
5.Excellent resistance to quickly crack propagation (RCP) ability.
6.Excellent flexible and resistance to scratches ability.
7.Good wear resistance, low wall friction coefficient, small flow resistance, excellent conveying ability.
8.Can use a variety of trench less ways, great convenient for construction and installation.
9.Low system cost, less maintenance costs, can dramatically reduce the cost for the project.
10.Long service life: dark bury PE pipe normal uses more than five years.11.PE material can be reused, complete with the concept of efficient environmental protection which our
state advocates .
11. Appearance: Yellow stripes
HDPE Gas Pipe with Gas Pipe Fittings
Standard: ISO-4427, DIN 8074, ASTM D3035, BS-6437, GB/T13663-2000
Technical requirements of the PE gas supply pipes:
Items |
technical requirements |
|
Appearance |
Outside and inner pipe surfaces shall be clean and smooth. Deficiencies including bubbles, obvious scratches, surface sinking, impurity and uneven colors are not allowed. Pipe ends shall be cut flat and keep vertical to the axis line. |
|
Thermal stability(200°C).min |
greater than 20 |
|
Elongation at break. % |
greater than or equal to 350 |
|
Vertical retraction(110°C), % |
less than 3 |
|
Melt Flow Rate(MFR). (190°C.5kg)g/10 min |
MFR rate of change less than 20% |
|
Hydrostatic strength (MPa) |
PE80 |
(1). 20°C. Hoop stress 9.0MPa,time to rapture≥100h (2). 80°C. Hoop stress 4.5MPa,time to rapture≥165h (3). 80°C. Hoop stress 4.0MPa,time to rapture≥1,000h |
PE100 |
(1). 20°C. Hoop stress 12.4MPa,time to rapture≥100h (2). 80°C. Hoop stress 5.4MPa,time to rapture≥165h (3). 80°C. Hoop stress 5.0MPa,time to rapture≥1,000h |
|
High-desity Polyethylene Pipe Series
