Help Center6KW Ultra High Frequency Induction Heating Machine
Related Products
-
Bearing Heating and Dismount Tools for Outdiameter 480mm BearingUS$ 450 - 1,000MOQ: 1 Set -
Bearing Induction Heater for 1KVAUS$ 450 - 1,000MOQ: 1 Set
-
Bearing Heater Machine /bear HeaterUS$ 450 - 1,000MOQ: 1 Set
-
Good Quality Bearing Induction Heater for New DesignUS$ 450 - 1,000MOQ: 1 Set
-
Induction Electric Boiler HeatingUS$ 1,200 - 15,000MOQ: 1 Set
Specifications
1.Welding reamer2.quenching sawtooth
3.rolling small drill
4.welding communication cable joint
5.welding filter capacit
Equipment Feature of DDCGP-06-II: ( frequency 200-700KHZ )
Main Application:
Welding reamer, quenching sawtooth , rolling small drill, welding communication cable joint ,welding filter capacitance
Main Feature:
1, While frequency up to 700 KHZ, it can effectively control the depth of hardening, particularly suitable for heating small workpiece and metallic wire etc parts.
2, Adopted IGBT power component and introduced our third generation of variable flow control technology, the equipment has higher reliability and low maintenance cost.
3, Machine with constant current/ constant power etc control function, heating efficiency is higher than others.
4, Front panel with full display function such as output power, frequency, and current.
5. Simple installation, as long as we connect machine with power supply and water, machine will work normally, professional installation is not required.
6, Small shape to save more installation place, and maintenance is more convenient.
7, Automatic control function, can adjust power and time at the process of heating, heat preservation, which is beneficial to improve the heating quality of repeatability, and simplify handling operation.
Technical Parameter
Model |
DDCGP-06-II( one type) |
Rated input voltage |
Single phase220V±10% 50 or 60Hz |
Output current |
5-30A |
Maximum output power |
6.6KW |
Oscillating frequency |
200-700KHz |
Duty Cycle |
80% 24 hours continuous work |
Cooling method |
Water temperature lower than 35 degree |
Cooling water pressure |
≥0.2MPa 3L/min |
...
