2 core ftth cable optical fibre cable GJXFH fiber optic cable price list
1.support 1-4 fiber
2.ftth
3.PVC or LSZH jacket

2 core ftth cable optical fibre cable GJXFH fiber optic cable price list





Description:

   The optical fiber unit is positoned in the centre. Two parallel Fiber Reinforced Plastics(FRP) are placed at the two sides. Then the cable is completed with a black or color LSZH sheath,the ftth cable is widely used in fiber to the home project .



Characteristics:

1.Special Low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property;

2.Two paralled FRP strength members ensure good performance of crush resistance to protect the fiber;

3.Simple structure, light weight and high practicability;

4.Novel flute desigh ,easily strip and splice, simplify the installation and maintenance;

5.Low smoke, zero halogen and flame retardant sheath





Technical Parameters

Fiber count	Cable Diameter  mm	Cable weight kg/km	Tensile Strength  Long/short term N	Crush Resistance Long/short term N/100mm	Bending Radius  Static/Dynamic    mm
1	(2.0±0.2)*(3.0±0.2)	8	30/60	300/1000	15/30
2	(2.0±0.2)*(3.4±0.2)	8.5	30/60	300/1000	15/30
1	(2.0±0.2)*(3.8±0.2)	9	30/60	300/1000	15/30
4	(2.0±0.2)*(4.0±0.2)	10	30/60	300/1000	15/30



Hanxin has more than 10 years' experience in R&D and manufacturing in the field of optical fiber communication, which is capable of producing  a variety of optical fibers according to diversified demands of customers.
