Help CenterPlastic Ball Manufacturing Machine / Ball Blow Moulding Machine
Related Products
-
Plastic Bottle Manufacturing Machine/ Bottle Blowing MachineNegotiableMOQ: 1 Set -
4L HDPE Bottle Making Machine/ Blow Moulding MachineNegotiableMOQ: 1 Set
-
Plastic Ball Making Machine / Ball Blow Moulding MachineNegotiableMOQ: 1 Set
-
4L PETG Bottle Making Machine, Full Automatic Blow Moulding MachineNegotiableMOQ: 1 Set
-
Full Automatic PETG Bottle Blowing MachineryNegotiableMOQ: 1 Set
This is plastic ball manufacturing machine / ball blow moulding machine, A wide variety of materials can be used for the machine, which are suitable for producing 100ml to 3L PE bottle. The clamping system is a high-precision double-station linear guide, extrusion system using a hard gear reducer and inverter. The die head system adopts central-incoming extrusion die made of special steel, imported hydraulic valve and seal parts with proportional control valve.The control system consists of PLC and Human-machine interface imported from Japan, and automatic temperature control module and imported electrical parts.
plastic ball manufacturing machine production process
plastic balls blowing machinery specification
Unit |
Item |
Specification |
Description |
|
Extruding system
|
Screw diameter |
Φ55mm |
Mixing model |
Max. Product Volume |
Φ50mm balls |
single station and double die-head |
|
Screw L/D |
24:1 |
|
|
Material of screw and barrel |
|
38CrMoALA |
|
Plasticizing capacity |
45KG/Hr |
Based on HDPE 5502 |
|
Extruding method |
|
Inverter motor, hardness tooth surface gear box |
|
Driving power |
15KW |
|
|
Screw revolution |
10—90rpm |
|
|
Heating zones |
3 |
Temperature module from Mitsubishi PLC |
|
Heating power |
8 KW |
Solid state (SSR) and plug connection for all heaters |
|
Blowers |
3 |
|
|
Cooling function |
Yes |
Cooling water for feeding zone and gear box |
plastic balls blowing machinery extruder- die head
plastic small bottle blow molding machine plastic plasticing part
Plastic sea ball blow moulding machine making step:
Zhangjiagang Plastic sea ball blow moulding machine , component brand
Zhangjiagang plastic blow molding machine, loading
Any inuqiry about small bottle blow molding machine , , blow moulding machine, please contact us! thanks!
