High flame retardance VW-1 permanent identification polyolefin cable marker sleeve /cable marker tags
KOSOO CTMS cable marker tags are designed to meet the requirements of high performance identification of wire and cable,tools,hose and equipment.Made from reliable flame-retardant polyolefin with outstanding properties,sleeves can also be used as electrical insulation.Marks are permanent after printing.
Description of cable marker tags
·Sleeves meet the requirements of AMS-DTL-23053/5 (materials and performance).
·Flexible, highly flame-retardant.
·Sleeves meet the print performance requirements of MIL-M-81531.
·Markers can also provide insulation and strain relief.
·Marks are permanent after printing; mark performance improves after shrinking.
·Free of PCBs, PCPs, polybrominated biphenyls (PBBs), polybrominated biphenyl oxides and ethers (PBBOs, PBBEs and PBDEs) and toxic heavy metal compounds, which are classified as environmentally hazardous substances. Conform to European RoHS environmental directive.
Detailed pictures of cable marker tags
Product sizes of cable marker tags
mm/inch
|
Size (inch) |
Inside diameter |
Recommended use range(MM/INCH) |
|
As supplied (min.) |
After recovery (max.) |
||
3/32 |
2.4 (0.093) |
0.8 (0.031) |
0.9-2.0 (0.035-0.079) |
1/8 |
3.2 (0.125) |
1.0 (0.042) |
1.1-2.7 (0.044-0.105) |
3/16 |
4.8 (0.187) |
1.6 (0.062) |
1.8-4.1 (0.069-0.160) |
1/4 |
6.4 (0.250) |
2.1 (0.083) |
2.3-5.5 (0.091-0.215) |
3/8 |
9.5 (0.375) |
3.2 (0.125) |
3.5-8.0 (0.137-0.320) |
1/2 |
12.7 (0.500) |
4.2 (0.166) |
4.7-10.8 (0.183-0.425) |
3/4 |
19.1 (0.750) |
6.35 (0.250) |
7.0-16.3 (0.275-0.640) |
1 |
25.4 (1.000) |
8.5 (0.333) |
9.3-21.6 (0.366-0.850) |
1 1/2 |
38.1 (1.500) |
19.1 (0.750) |
21.0-33.0 (0.825-1.300) |
2 |
50.8 (2.000) |
25.4 (1.000) |
27.0-48.0 (1.063-1.890) |
Packing of cable marker tags
On spools (continuously flat tubing or non-continuous pieces,2inch/pieces).
Certifications of cable marker tags
Guangzhou Kaiheng K&S Co.,Ltd is a major supplier of Heat shrinkable tubing offering good quality products at competitive price.We are specialized in this filed for over 15 years.We manufacture and distribute a broad range of heat shrinkable tube,PVC tube.Trademarked as KOSOO. Our products meet international standards such as UL,CSA and Milspec as well as international environmental demands.
1.Reply your inquiry in 24 working hours.
2.Delivery the goods to our customer all over the world with speed and precision.
3.Offer the goods with superior quality.and competitive price.
4.100% QC inspection before shipment.
