300mm Digital Horizontal Profile Projector HB12-2010
- 0 per Month
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Jaten | Model Number: | HB12-2010 |
Product Description
HB12-2010 Product Features:
l 300mm diameter screen with digital protractor;
l 200X100mm precision movement work-stage;
l Work-stage sway range between ±15°;
l Halogen profile and fiber surface illumination adjustable;
l Geometric multifunction data processing system DRO DP300;
l Built-in Mini-printer;
l Available 10x,20x,50x, objective rotary table and foot-switch, etc.
Specifications:
Reverse Image | HB12-2010 |
Obverse Image | HB12-2010Z |
Metal Stage Size | 408 x 126mm |
Stage Travel: X and Y-axis | 200 x 100mm |
Stage Travel:Y-axis | 75mm (for focusing) |
X and Z Linear Resolution | 0.0005 mm |
Sway Range | ±15° |
Accuracy | ≤3+L/200(um) |
Screen | Diameter :Ø330mm,Effective Range ≥ Ø300(with “* ” Reticle) |
Rotary Range: 0~360° ; Resolution Rotary Indicator: 1’ or 0.01° | |
Digital Readout | DP 300 (561-301) Multifunctional Data Processing System |
Illumination | Contour illumination:24v/150w (halogen Lamp ) |
Surface illumination:21v/150w (Optical Fiber) | |
Power Supply | AC110V/60Hz; 220V/50Hz, 650W |
Dimension (D×W×H) | 1160 x 600 x 960mm |
Packing Dimension (L×W×H) | 1300 x 880 x 1250mm |
Gross/Net Weight | 200/160Kg |
Standard Delivery:
Product Name | Product Name | Product Name |
Digital Readout DP300 | 10X Objective | Screen Clamp Device |
Built-in Mini-printer | Power Cable | Operation Manual |
Optional Accessories:
Product Name | Product Name | Product Name |
Measuring Software | Rotary Vise | Edge Detector |
20X Objective | 50X Objective | 100X Objective |
Holder Clamp | V-shape Clamp | Swivel Center Support |
Working Cupboard | Over-Chart | Foot-Switch |
